CABLE RAILING

SWAGELESS NON-TENSIONING FITTINGS FOR METAL POSTS

Push-Lock®
The Push-Lock® Threaded Bolt fitting is installed into
a pre-drilled and tapped hole. This fitting is furnished
with a Delrin® washer that is installed between the
shoulder of the fitting and the end post to protect the
Push-Lock® surface of the end post.
Threaded Bolt CABLE ITEM
NO.
DIA.
1/8" PL-FM-MS-4
3/16" PL-FM-MS-6

Push-Lock®
Threaded Clevis
The Push-Lock® Threaded Clevis fitting is installed into
a pre-drilled and tapped hole in the end post. The cable
attaches to the body via the Push-Lock® locking wedge
system.
CABLE ITEM
DIA. NO.
The most 1/8" PL-CL-RP-4
Pull-Lock® common option 3/16" PL-CL-RP-6
STAINLESS & CABLE RAILING

The Push-Lock® fitting is The Pull-Lock® fitting is installed into a pre-drilled hole
installed into a pre-drilled POST PARAMETERS FOR in the end post. Using the Pull-Lock® fitting on level or
hole in the end post. Using PUSH-LOCK® & PULL-LOCK® pitched runs requires enough clearance on the back side
the Push-Lock® fitting FLAT SIDED FRAME "F" of the end post to install the fitting through the back side
requires enough clearance of the post. That amount of clearance depends on the
on the back side of the length of Pull-Lock® chosen.
end post. The amount of
clearance depends on the
length of the Push-Lock®
fitting chosen.
* Push-Locks® & Pull-Locks® cannot be used with
angle shapes or flat bar in pitch applications
unless the post hole is drilled at the angle of the
stair rake and a beveled washer is used.
ROUND TUBE PIPE FRAME
FRAME "R" "P"

SIZE "T" "D"
1-1/4" 1.25" 1.66" METAL FRAMING OPTIONS FOR PULL-LOCK® FITTINGS
1-1/2" 1.5 1.91"
2" 2.00" 2.375" FRAME FRAME FRAME 1/8" CABLE 3/16" CABLE "L"
"F" "R" "P" ITEM NO. ITEM NO. LENGTH
1-1/2" 1-1/2" 1-1/4" PUL-4-12 PUL-6-12 1.562"
METAL FRAMING OPTIONS
FOR PUSH-LOCK® FITTINGS N/A N/A 1-1/2" PUL-4-1.810 PUL-6-1.810 1.810"
FRAME FRAME FRAME 1/8" CABLE 3/16" CABLE "L" 2" 2" N/A PUL-4-2.030 PUL-6-2.030 2.030"
"F" "R" "P" ITEM NO. ITEM NO. LENGTH N/A N/A 2" PUL-4-2.300 PUL-6-2.300 2.300"
1-1/2" 1-1/2" 1-1/4" PL-4-12 PL-6-12 1.562" 2-3/8" 2-3/8" N/A PUL-4-2.375 PUL-6-2.375 2.375"
2" 2" 1-1/2"† PL-4-2.030 PL-6-2.030 2.030" 3" 3" N/A PUL-4-3.030 PUL-6-3.030 3.030"
3" 3" N/A PL-4-3.030 PL-6-3.030 3.030" 2-1/2" 2-1/2" 2-1/2" PUL-4-2.530 PUL-6-2.530 2.530"
† will protrude from cable side of post +/- 1/8" 3-1/2" 3-1/2" 3" PUL-4-3.030 PUL-6-3.030 3.030"
