CABLE RAILING

ACCOMPANYING FITTINGS FOR METAL POSTS

Invisiware® Threaded Tab for attaching an Adjust-A-Jaw® Mounting Screw
and Threaded Tab, Adjust-A-Body® with Threaded Eye and Stainless steel steel socket-head screws for mounting
Threaded Tab, Fixed Jaw and Threaded Tab, Clip-On Fixed an Adjust-A-Jaw® and Threaded Tab, Adjust-A-Body®
Jaw and Threaded Tab and Push-Lock® Threaded Eye and with Threaded Eye and Threaded Tab, Fixed Jaw and
Threaded Tab. Threaded Tab, Clip-On Fixed Jaw and Threaded Tab and
Push-Lock® Threaded Eye and Threaded Tab.

CABLE DIA. ITEM NO. THREAD
CABLE DIA. ITEM NO. 1/8" & 3/16" SC-6 1/4-28
1/8" & 3/16" TT-6B

The Ferrule is used for attaching the Adjust-A-Jaw® and Threaded Tab, Adjust-A-Body® with Threaded Bolt, Adjust-A-
Body® with Threaded Eye and Threaded Tab, Fixed Jaw and Threaded Tab, Clip-On Fixed Jaw and Threaded Tab onto cable.

CABLE ITEM AFTER SWAGED
DIA. NO. "D" DIA. "L" LENGTH
1/8" F-4 .25" .61" Ferrule before
3/16" F-6 .25" .56" swaging
STAINLESS & CABLE RAILING ACCOMPANYING FITTINGS FOR WOOD POSTS

Stainless Steel Post Protector Tube will keep the cable
from biting in the wood, the post protector tube is Stainless Steel Washer
inserted into a wood post where the cable enters/exits
the post at a angle.
ITEM NO. WASHER O.D. WASHER I.D. CABLE DIA.
ITEM NO. CABLE DIA. 7/16SAE 59/64" 31/64" 1/8" & 3/16"
CS-TUBE 1/8" & 3/16"

Lag Eye is a convenient, easy-to-install means
for attaching an Adjust-A-Body® with Threaded Eye,
Adjust-A-Jaw®, Fixed Jaw, or Push-Lock® with Threaded
Eye to a wood post.

The Ferrule is used to retain an Adjust-A-Jaw®,
Adjust-A-Body® or a Fixed Jaw onto cable.

CABLE ITEM AFTER SWAGED
DIA. NO. "D" DIA. "L" LENGTH
MINIMUM
CABLE
1/8" F-4 .25" .61" DIA. ITEM "G" "H" "T" "S" "L" TIMBER SIZE
NO.
3/16" F-6 .25" .56"
Ferrule before 1/8" & 3/16" LE-6 .232" .735" .256" 1.50" 2.23" 4x4
swaging
Mounting Screw
Stainless steel socket-head screws for mounting an
Adjust-A-Body® with Threaded Eye, Adjust-A-Jaw®,
Fixed Jaw, or Push-Lock® with Threaded Eye.

CABLE DIA. ITEM NO. THREAD
1/8" & 3/16" SC-6 1/4-28
