CABLE RAILING

OPTION 1: CABLE ON A SPOOL, SWAGE-ON FITTINGS, SWAGER RENTAL KIT
For larger cable installations consider spooled bulk cable, swage-on fittings and a swager rental kit. Choose
your cable size and feet required, fixed end and tensioning end fittings.

Step 1: Choose cable size and feet required

Ultra-Tec® recommends using 1x19 Type 316 stainless 1/8" CABLE PART NO.
steel L/H lay strand (or cable) for railing infill because of PER FOOT* 4AS2
its strength, for its diameter, its resistance to corrosion, 100FT 4AS2-100FT
and its compatibility with stainless steel hardware. 500FT 4AS2-500FT
Choose from 1/8" and 3/16" diameters.
1/4", 5/16" and 3/8" cable is also available. 3/16" CABLE PART NO.
PER FOOT* 6AS2
100FT 6AS2-100FT
500FT 6AS2-500FT
*spooling fee will apply

Step 2: Choose Swaged Tensioning Fitting

See page 246 for Metal
See page 250 for Wood
STAINLESS & CABLE RAILING

Step 3: Choose Swaged Non-Tensioning Fitting

See page 247 for Metal
See page 251 for Wood

Step 4: Choose a Swager Rental Kit

See page 256

Step 5: Choose Accessories

See page 254-256
Scan the QR Code to view a
video which demonstrates
swaging studs onto cable
and installing Invisiware®
Receivers in metal posts.
