Page 316 - Catalog

MORTISE GATE LOCK KIT

FORTYLOCK INSERT LOCK KIT 2" TUBING

SET50ALUSTD (for 2" square post)
(Kit handle is Insert lock with 100% stainless steel mechanism. The stainless steel and adjustable
shown below)
self-latching bolt combined with the right keep guarantee a strong and solid closed gate
where the gate wings can not be pulled apart or forced open. The lock can be installed on
metal, aluminum, PVC and wood gates. Thanks to the patented “Click-It” system, the lock
can be installed in a matter of minutes.
• Lock mechanism with cover plate against dirt penetration
• Patented “Click-It” system makes tapping thread in the profile unnecessary
• Continuous adjustment of the daybolt up to 3/8" without dismounting the lockbox
• Key-operated self-latching bolt
• Mechanism, hook, frontplate, latchbolt: stainless steel
• Easy left or right
changing of the
SET50ALU-STD 2" KIT INCLUDES: self-latching daybolt
Lock, • Stainless steel hook
2 Aluminum Cover Plates (3020-HYB-ALU), for secure anchoring
Cylinder (3012-60-STD-VSZ), • Throw of the hook:
Aluminum Handle Set (3006M-H) and 11/16"
Keep (SFKB-QF40) • Center-distance
cylinder <=>
handles => 3-5/8"
• Compatible with
all Europrofile
cylinders

ELECTRIC STRIKE FOR MORTISE GATE LOCK AND KEEP
INSERT LOCKS H-METAL for 2-1/2" Square Tubing
SEH SEHE - Electric strike, fail secure for Mortise lock with 100% stainless steel mechanism. This model can be installed on steel,
insert locks aluminum, or wood gates. The combination of the hook (dead bolt) with the SHKM keep
SEHR - Electric strike, fail open for provides a secure anchoring of your gate while preventing the gate from being pried open
insert locks as the dead bolt’s “hook” locks into the keep’s anchoring plate.
This electric strike is for swing • Easy left or right hand changing of the self-latching bolt Min. 7/8"
gates using our Mortise locks. • Adjustment of the latch bolt up to 3/4" 1-3/16"
The strike is equipped with a continuous without removing the lock 1-7/16"
double blocking system which • Mechanism, hook, front plate, latchbolt: stainless steel
supports 1000 lb (500Kg) • Throw of the hook: 1-1/4"
pulling-force. This keep is 3-5/8"
extremely strong and the ideal (Kit handle is 7-1/8"
solution for your access control shown below) 1-9/16" 8-11/16"
installations. The electric strike
HARDWARE • Extremely strong and H-METAL Lock for 2-1/2" Square Tube, 1-3/8" 2-3/16" 1/8"
is available in a Fail Secure or
GATE Fail Safe model. H-METAL-SET-80M KIT INCLUDES:

Cylinder (3012-80-STD-VSZ),
• user-friendly design 2 Polyamide Cover Plates (3020-HYB-STD),
Easy left or right hand
changing Aluminum Handle Set (3006M-H) and
• For profiles 2" and larger Keep (SHKM) Keep and
• Voltage: 12 V AC/DC cylinder
• Water resistant, common style
weatherproof to both kits
H-METAL-SET-80I KIT INCLUDES:
Recommended gap 7/8". H-METAL Lock for 2-1/2" Square Tube,
2 Stainless Steel Cover Plates (3020-HYB-A2),
Cylinder (3012-80-STD-VSZ),
Stainless Steel Handle Set (3006I-H) and
Keep (SHKM)
A LL DIMENSIONS ARE APPR O XIM ATE .
