GATE CLOSERS

TB SERIES 200 / 400 / 600 GATE CLOSERS

Lockey Hydraulic Gate Closers TB200/400/600, also known as a Pedestrian Gate Closer,
does not slam gates shut. It firmly and quietly pushes gates closed, making it ideal for
use with magnetic locks and other latching devices. The closing speed is pre-set to
provide a controlled close of 8 seconds or more, depending upon the weight of the gate
and quality of hinges. With this closer there is no risk of maladjustment or tampering
with the speed adjustment after it is fitted.
Each gate closer includes instructions, mounting brackets and fitting bar. As with most
gate closers, it is advisable to install a mechanical stop to restrict the gate opening
angle** to avoid damage to the closer. (NON FIRE RATED)
• Easy to install
TB200BL - Light Duty Closer • Installs on side, top, middle or bottom of right or left hand gates
in Black • Mounts on opening side of gate, pushing the gate closed
TB200SS - Light Duty Closer in • Maximum opening angle of 110 degrees** (LockeyUSA® recommends use of a
Stainless Steel mechanical stop to restrict opening angle)
• Closers available in black and stainless steel finishes
TB400BL - Medium Duty Closer
in Black Technical Overview
TB400SS - Medium Duty Closer
in Stainless Steel TB200 (Light Duty) TB400 (Medium Duty) TB600 (Heavy Duty)
Max. Gate Weight 50-125 lbs. 75-175 lbs. 150-250 lbs.
TB600BL - Heavy Duty Closer Max. Gate Width 36-52 in. 40-64 in. 44-72 in.
in Black Max. Opening Angle 110 degrees** 110 degrees** 110 degrees**
TB600SS - Heavy Duty Closer Type of Gate Material Vinyl, Steel, Wood Vinyl, Steel, Wood Vinyl, Steel, Wood
in Stainless Steel Closing/Latch Method Hydraulic/Nitrogen Gas Hydraulic/Nitrogen Gas Hydraulic/Nitrogen Gas
Material Steel/Stainless Steel Steel/Stainless Steel Steel/Stainless Steel
Color Black or Stainless Steel Black or Stainless Steel Black or Stainless Steel
Hinge Arrangements In-line or Offset In-line or Offset In-line or Offset
Opening Pressure Approx. 3-7 lbs. Approx. 6-12 lbs. Approx. 8-18 lbs.

CHAINLINK MOUNTING KIT COMPATIBLE
WITH TB200/400/600

• Works on Fence Posts 2" - 2-7/8"
Includes
- One Post Bracket
- One U-Bolt
- Two Machine Screws
TBLINX Steel - Four Lock Nuts

GATE HARDWARE
SPRINGS FOR WOOD GATES
• Safe & easy installation – No special tools required
• Long life – Tested to over 1 million cycles
• Safety – Tension adjustable to ensure gate closes long after
11" Spring installation
410001
• Easy to adjust – Springs include stickers to assist consumer in
14" Spring adjusting tension
410002

A LL DIMENSIONS ARE APPR O XIM ATE .
