ELECTROMAGNETIC LOCK

ELECTRO MAGNETIC LOCK WITH OR

WITHOUT HANDLE

Magnetic lock with or without handle. Available in 2 versions.
MAG2500/MAGMAG-2500 with 600 lb. and MAG5000/MAGMAG-5000
with 1200 lb. of pulling force. The aluminum powdercoated housing
equipped with the unique Quick-Fix fixings ensures a fast and nicely
finished mounting. Eliminate time-consuming welding; drilling 5 holes
is enough to fix the lock. A two layer, protective coating guarantees
that our electro-magnetic locks are ready for years of worry free use
outside.
MAGMAG2500SL - Silver without Handle
MAGMAG2500BL - Black without Handle • High holding force! Up to 1200 lb/500 kg
For mounting on square posts and gate profiles of • 500h salt spray resistant!
1-1/2" to 3-1/8", 600 lbs. pulling force • • Special two-layer protective coating developed for outdoor use
SGS Certified
MAGMAG5000SL - Silver without Handle • Powdercoated aluminum casing
MAGMAG5000BL - Black without Handle • Anti-residual magnetism kick-off system
For mounting on square posts and gate profiles of • New anti-pry system: Raised edge on the magnet housing makes it
1-1/2" to 3-1/8", 1200 lbs. pulling force impossible to put a crowbar between the magnet and the armature
plate
MAG2500SL - Silver with Handle • No-handle version
MAG2500BL - Black with Handle • Fast and easy fixing by means of 5 holes with Quick-Fix
For mounting on square posts and gate profiles of • Same center-distance as the standard Locinox keeps
1-1/2" to 3-1/8", 600 lbs. pulling force • MAG2500/MAGMAG2500: Minimal pulling force: 2500N (600 lb)
• MAG5000/MAGMAG5000: Minimal pulling force: 5000N (1200 lb)
MAG5000SL - Silver with Handle • Voltage: 12V/24V DC
MAG5000BL - Black with Handle • Current MAG2500/MAGMAG2500: 460 mA / 12 V or 230 mA / 24 V
For mounting on square posts and gate profiles of • Current MAG5000/MAGMAG5000: 460 mA / 12 V or 230 mA / 24 V
1-1/2" to 3-1/8", 1200 lbs. pulling force

PULL HANDLE SET PROFILE FOR MAGLOCKS

3006PULL.BL - Black NLINE.BL - Black
3 NLINE.SL - Silver Powdercoated aluminum design
3006PULL.SL - Silver006PULL.SL - Silver
T Thishis aluminum powderwder profile (sawable) for aesthetic
aluminum
po
coated handle set has
coated handle set has an Only for finishing of the openings between
elegant design and could
elegant design and 2500 profile. 2 Maglock components. Prevents
be used in combination
be used in passers to stumble against the
with magnetic locks (e.g. if
with magnetic locks (e.g. if Maglock parts.
used top/bottom), or any
used top/bottom), o
gate that needs a sturdy
gate that needs a sturdy • Several fill-in configurations
and elegant pull handle
and elegant pull handle possible: between 2 Mag
independent of the latching
independent of the latching locks, and 3006Pull handle or
mechanis
mechanism. between bottom and top of
the gate
• 2 plastic cover caps and 4
in-between caps included
• Profile length: 6 feet
• Delivered with self drilling GATE
screws HARDWARE
SAFETY POWER SUPPLY 12 V
T12VDC
· Plug in transformer with screw terminal
connections
· Primary: 120VAC, 60 Hz
· Secondary: 12VDC, 1000mA
· LED Indicator
· Indoor Use
A LL DIMENSIONS ARE APPR O XIM ATE .
