STEEL GATE HINGES

All sold individually.

2 FLAG WELDING HINGES
(sold individually) Capacity Clamp Hinge Holed Pivot
per pair with Square
Base for
Clamp Hinge

Weight 220 lbs. 180-M18 190-30
capacity Approximately 4-1/4" For 1-1/4" square post
Item # Height per pair
RIGHT HAND HINGE long x 1-1/2" wide
430DX-60 2-3/4" 330 lbs R: 1-3/4" - 2-3/4"
430DX-100 4" 675 lbs
430DX-140 5-1/2" 1000 lbs 570 lbs. 180-M27 190-40
For 1-1/2" square post
Approximately 5-1/2"
430DX-200 8-1/2" 1350 lbs
long x 2" wide
R: 2-1/4" - 3-3/4"
LEFT HAND HINGE
430SX-60 2-3/4" 330 lbs door / gate
430SX-100 4" 675 lbs steel welding
430SX-140 5-1/2" 1000 lbs
430SX-200 8-1/2" 1350 lbs
grease fitting

adjustment
key “R”
Weight
capacity
Item # Height per pair
connecting
pin
564-100 4" 330 lbs
564-120 4-3/4" 500 lbs R
564-140 5-1/2" 585 lbs
564-160 6-3/8" 675 lbs
564-180 7-1/4" 740 lbs

Upper hinge with Bottom hinge with thrust
L plate bearing and plate
the fixing and
steel pillar / wall adjustment plate “R”
87PST-P
• Height of bearing: 1-1/2"
adjusting and • Diameter of Bearing: 1-3/4"
fastening screw
steel pillar / wall GATE HARDWARE
bearing housing R
ø 45 mm
86L-P
• Total height: 3-3/4"
• Total width: 4" fixing
screws
• Diameter of bearing: 1-3/4" Capacity 440 lbs.
• R: 2" - 3-1/4" R per pair
radial bearing ø 45 mm
floor
adjusting and fastening
screws “R”
A LL DIMENSIONS ARE APPR O XIM ATE .
