STEEL & STAINLESS STEEL ROLLER BEARING HINGES

Steel Roller Bearing Hinges Hinges sold individually
KEY FEATURES Heavy Duty Steel Roller Bearing Hinge
• Two sealed maintenance free bearings KEY FEATURES
(no greasing) • Three sealed maintenance free bearings (no greasing)
• Adjustable yoke for perfect installations • Adjustable yoke for perfect installations
• Ideal for both flat and round post • Ideal for both round and flat post installations
installations
Rusted Look • Load rating per gate: 2,000 lbs (900kg) • Load rating per gate: 3,000 lbs (1,360kg)
CI3000 CI3100 • Maximum gate weight: 1,100 lbs (500kg) CI3500 • Maximum gate weight: 1,500 lbs (680kg)

Light Duty Steel Roller Bearing Hinges Steel Roller Bearing Hinge
KEY FEATURES KEY FEATURES
• One sealed maintenance free bearing • Three sealed maintenance free bearings (no greasing)
• Adjustable yoke for perfect installations
(no greasing)
• Slotted for easy adjustment • Ideal for both round and flat post installations
• Upgraded yoke and grade 8 bolt (Shaft)
Rusted Look • Ideal for flat or round post installations CI3520 • Load rating per gate: 3,000 lbs (1,360kg)
• Load rating per gate: 500 lbs (230kg)
CI3600 CI3620 • Maximum gate weight: 1,500 lbs (680kg
• Maximum gate weight: 300 lbs (140kg)
Face Mount Weld-on Hinge
VersaWeld™ KEY FEATURES
KEY FEATURES • Two sealed maintenance free bearing (no greasing)
• Two sealed maintenance free bearing (no greasing) • Ideal for flat or round post installations
• Ideal for flat or round post installations • Load rating per gate: 2,000 lbs (900kg)
• Load rating per gate: 2,000 lbs (900kg) • Maximum gate weight: 1,100 lbs (500kg)
• Maximum gate weight: 1,100 lbs (500kg) CI3050
CI3075
Self-Closing Steel Roller Bearing Hinge Stainless Steel Roller Bearing Hinge
Self closing KEY FEATURES KEY FEATURES
max. gate • 304 stainless steel includes the bearings, shaft
weight • Two sealed maintenance • 5 Tension adjustment (bolt), washers and lock nut
300lbs free bearings (no greasing) settings • Two sealed maintenance free bearings (no
• Easy to install, heavy duty • Load rating per gate: greasing)
self-closing hinge 2,000 lbs (500kg) • Adjustable yoke for perfect installations
• Set includes one self-clos- • Self-closing maximum CI3800 • Ideal for both flat and round post installations
ing hinge and one Original gate weight: 300 lbs • Load rating per gate: 2,000 lbs (900kg)
BadAss hinge (130kg) • Maximum gate weight: 1,100 lbs (500kg)
• Adjustable yoke for perfect • Gate swings from
CI3850 installations -50 to 1100
Gap # Of Max Gate Max Gate
Product Yoke Body Height Weight
Number Product Name Variance Finish Sealed Weight Load Mat’l* Mat’l inch/mm lbs/kg
Inch/mm** Bearings lbs/kg lbs/kg
2.4-2.9" 1,100 lbs 2,000 lbs 3.8" 2.5 lbs
CI3000 Original BadAss Zinc 2 Steel Steel
(61-74mm) (500kg) (900kg) (97mm) (1.1kg)
1/2"-1" 1,100 lbs 2,000 lbs 3.8" 1.8 lbs
CI3050 Face Mount Weld-on BadAss Zinc 2 Steel Steel
(12-25mm) (500kg) (900kg) (97mm) (0.8kg)
Fixed 2-3/4" 1,100 lbs 2,000 lbs 3.75" 2.2 lbs
CI3075 VersaWeld™ BadAss Zinc 2 Steel Steel
(70mm) 1,100 lbs 2,000 lbs (95mm) (1.0kg)
(500kg)
(900kg)
2.5 lbs
3.8"
2.4-2.9"
HARDWARE CI3500 Heavy Duty BadAss (61-74mm) Zinc 3 1,500 lbs (1,360kg) Steel Steel (97mm) (1.6kg)
GATE CI3100 Original BadAss Rusted (61-74mm) Unfinished 2 (500kg) (900kg) Steel Steel (97mm) (1.1kg)
3.8"
3.5 lbs
2.4-2.9"
3,000 lbs
(680kg)
CI3520 100 Year BadAss 2.5-3.0" Zinc 3 1,500 lbs 3,000 lbs Steel Steel 4.1" 3.5 lbs
(64-76mm) (680kg) (1,360kg) (104mm) (1.6kg)
2.5-3.0" 300 lbs 500 lbs 1.3" 1 lbs
CI3600 Baby BadAss Zinc 1 Steel Steel
(64-76mm) (140kg) (230kg) (33mm) (0.5kg)
2.5-3.0" 300 lbs 500 lbs 1.3" 1 lbs
CI3620 Baby BadAss Rusted Unfinished 1 Steel Steel
(64-76mm) (140kg) (230kg) (33mm) (0.5kg)
2.4-2.9" 300 lbs 2,000 lbs 5.0" 5.5 lbs
CI3850 Self-closing BadAss Set † † Zinc 2/2 Steel Steel
(61-74mm) (140kg) (900kg) (127mm) (2.5kg)
2.4-2.9" 1,100 lbs 2,000 lbs 3.8" 2.5 lbs
CI3800 Stainless Steel BadAss † Zinc 2 Stainless Stainless
(61-74mm) (500kg) (900kg) (97mm) (1.1kg)
A LL DIMENSIONS ARE APPR O XIM ATE .
