Page 359 - CATALOG

STEEL HINGES FOR WOOD, VINYL & METAL GATES

Hinges sold per pair

KMS-DCH-4
Made in
the USA
310004
4" Mild Steel Commercial Post & Wall Mount Dallas Hinge
Heavy Duty Traditional For Use With: Iron and Wood
8" T-Hinge Originally designed for the Dallas Cowboy Stadium, in Dallas, Texas,
these are true 180 degrees hinges. Designed to mount on wall or pillar
face larger than 4", with a minimum gate frame of 3/4".
Furnished with 1/4" Super Tek Screws.

310007

Heavy Duty Contemporary KCLH-4D
8" T-Hinge
Made in
the USA

4" Mild Steel Hot-Dipped Galvanized Brackets
For Use With: Chain Link and Pipe Steel
4" diameter post side bracket with a gate side bracket for a 1-5/8" to
310006 1-7/8" diameter gate frame. Swings 180 degrees.
Heavy Duty Traditional
8" Strap Hinge
KMS-HDEMBCHS

Made in
the USA

Mild Steel Adjustable Commercial Duty Embassy Hinge
310008 For Use With: Iron and Wood
Made of Stainless steel, with mild steel brackets. Designed for use with
Heavy Duty Contemporary
8" Strap Hinge steel or iron gates. Gate side bracket adjusts 1/2"- 2-3/4". Mild steel
bracket and stainless steel t-rod and nuts.
Furnished with 5/16" large Super Tek screws for installation. Fits 2" post,
2" gate frame. Removable E-Clip, furnished with security screw.
Commonly used on drive gates and enclosures. Use stainless steel
310009 version on aluminum gates or harsh environments. Swings 180 degrees.
Contemporary
8" Butterfly Hinge KMS-HDEMBIHS
Made in GATE HARDWARE
the USA

Mild Steel Adjustable Industrial Duty Embassy Hinge
For Use With: Iron and Wood
Made of Stainless steel, with mild steel brackets. Used with large scale
310010 steel and iron gates. Gate side bracket adjusts from 5/8" - 3", stainless
steel T-Rod, nuts, self-lubricating bushing and Super Tek Screws for
Traditional locating of hinges. Removable E-Clip, furnished with security screw.
8" Butterfly Hinge
Commonly used on large drive gates and enclosures, zoo fencing and
high security settings.
A LL DIMENSIONS ARE APPR O XIM ATE .
