Page 472 - CATALOG
P. 472
SLIDE GATE OPERATOR
POST MOUNTED SLIDE GATE OPERATOR
Rotary Gate Systems slide gate operators mount directly to a fall-over support post
and allow for installation where pad mounted, chain drive operators are not desirable
or practical. These rack drive operators are a natural fit for DuraGates cantilever
hardware and provide much more security than chain or drive rail operators.
TECHNOLOGY TECHNICAL FEATURES
> Full Systems Capable Controller > Capacity: 1,500 or 2,500 lbs
> Inherent Reverse Sensor > Gate Speed: 1.1 ft/sec, not adjustable
(UL 325 type A obstruction sensor) > Motor: 24VDC, high torque permanent
> Multiple Opening options on power outage magnet DC motor
> Mechanical limit switches > Soft Start / Stop adjustable in programming
> Key Secured Emergency Release > Drive: Rack direct drive 93:1 gear reduction
USAGE > Power Supply: 115 VAC
> Residential/Industrial Focus > Radio Controls: Optional Linear MegaCode
> Duty Cycle: Continuous > Dimensions: Operator- 26"H x 8"Dia, Control
> Rack drive applications Box 18"x18"x6"
> Small footprint > Weight: Operator 47 Lbs, Control box 45 Lbs
> Warranty* 5 years for operator, > UL Listed for Class I,II,III and IV applications
2 years for controller > UHMW Nylon Rack Gear Provides Years of
– DuraGates Hardware Service
– Integrator Drive Hardware
– Ranger Telescoping Systems
– V-Groove Hardware
* This warranty only extends to the distributor and
the installing dealer.
OPERATOR KITS INCLUDE:
> Operator
> Control Box w/ 110V outlet
> 20ft UHMW Nylon Gear Rack
COMMERCIAL MODEL INDUSTRIAL MODEL
Electromechanical operator for sliding Electromechanical operator for sliding
gates up to 1,500 Lbs and 35 Ft gates up to 2,500 Lbs and 45 Ft
SL-c SL-i
37-001
UHMW Nylon Gear Recommended to mount rack rail on
Rack, 5 Ft Mounting a 2x2 angle to cover the teeth.
hardware included.
