Page 474 - CATALOG

SLIDE GATE OPERATORS

Model SL-90DC SLIDE GATE OPERATOR

Electromechanical operator for chain or rack driven sliding gates up to
1600 Lbs and 50 Ft at 12 in/sec
Solar Panel
TECHNICAL FEATURES USAGE sold separately.
> Capacity: 1600 lbs and 50 Ft gate > Residential and Commercial Focus
> Gate Speed: 1 ft/sec > Duty Cycle: Continuous
> Drive: Chain or Rack drive > Battery backup integrated w/ (2) 7Ah 12VDC batteries
(at 11-1/2" O.C. vertical) > Solar option available
> Motor: 24 VDC, 1/2 HP > Warranty 7 years for residential, 5 years for commercial
> Power Supply: 115/230 VAC
Single Phase or 24VDC Solar Panel SL90DC-C Chain drive operator
> Radio Controls: Optional Linear MegaCode Includes 20' of #40NP chain, Bolt-on bracket, integrated
> Dimensions: 16"H x 15-1/2"W x 18-1/2"D battery backup.
> Weight: 95 lbs
> ETL Listed for UL 325 2018 Compliant SL90DC-C-S Chain drive operator Solar Powered
> Pre-wired loop rack is included Includes 20' of #40NP chain, Bolt-on bracket, integrated
> Mechanical Foot Pedal Release battery backup upgraded to (2) 14Ah batteries and SOLAR
controller installed, NO 110VAC power supply input.
SL90DC-R Rack drive operator
Includes pinion gear upgrade, rodent plate, and integrated
battery backup.
SL90DC-R-S Rack drive operator Solar Powered
AOM-PS-90/100 Includes pinion gear upgrade, rodent plate, and integrated
Pipe Stand Mount Kit AOM-90-PDT battery backup upgraded to (2) 14Ah batteries and SOLAR
Pedestal Mount Kit controller installed, NO 110VAC power supply input.

Shown SL90DC-C. Chain drive operator
for sliding gates.

AUTOMATION 472 SALES@LOCKS4GATES.COM ✛ LOCKS4GATES.COM
GATE Visit locks4gates.com to view the latest models and download spec sheets and installation manuals.
T: 908.757.2323 ✛ F: 908.757.3439
