Page 477 - CATALOG

SWING GATE OPERATORS

Model SW-325DC SWING GATE OPERATOR

Electromechanical operator for swing gates with bottom articulating arm up to
2000 Lbs and 22 Ft

TECHNICAL FEATURES
> Capacity: 2000lbs and 22 Ft gate
> Cycle time: 14 - 25 seconds, adjustable
> Drive: Bottom mounted articulating arm
> Motor: 24 VDC, 1/2 HP
> Power Supply: 115/230 VAC Single Phase Solar Panel
or 24VDC Solar Panel sold separately.
> Radio Controls: Optional Linear MegaCode
> Dimensions: 21"H x 25-1/2"W x 19"D
> Weight: 160 lbs. + 30 lb. Arm SW-325DC Swing gate operator
> ETL Listed for UL 325 2018 Compliant Includes articulating arm, integrated battery backup.
> Pre-wired loop detector rack is included SW-325DC-S Swing gate operator Solar Powered
> Easy Slide Quick Release Arm Includes articulating arm, integrated battery backup
upgraded to (2) 14Ah batteries and SOLAR controller
USAGE installed, NO 110VAC power supply input.
> Residential and Commercial Focus
> Duty Cycle: Continuous
> Battery backup integrated w/
(2) 7Ah 12VDC batteries
> Solar option available
> Warranty 7 years for residential,
5 years for commercial AOM-SPT-325 AOM-SPD-325
Pipe Stand Mount Kit Pedestal Mount Kit

Model TORO PRIME SWING GATE OPERATOR

Electromechanical screw type arm operator for swing gates up to
1,600 Lbs and 8 Ft OR 600 Lbs and 18 Ft

TECHNICAL FEATURES
> Capacity at max weight: 1600 lbs/8 Ft; 1200 lbs/12 Ft
> Capacity at max Length: 800 lbs/16 Ft; 600 lbs/18 Ft
> Cycle time: 15 - 20 seconds, adjustable
> Drive: Screw Drive
> Motor: NA Toro operators are sold a la carte.
> Power Supply: 115/230 VAC Single Phase and One or two actuators, a controller, and
24VDC Solar Panel accessories as needed.
> Radio Controls: Optional Linear > Dimensions: Control
box 15-3/4"H x 19-3/4"W x 8"D
> Weight: Arm: 25 Lbs; Control box: 55 Lbs T24-PRIME Operator actuator arm
> ETL Listed for UL 325 2018 Compliant T24-CB TORO control box, 110VAC input power, with
> Pre-wired loop detector rack is included integrated battery backup
> Keyed Manual Release
T24-CB-S TORO control box, Solar Power Input, with
USAGE upgraded battery backup (2) 14Ah 12VDC batteries, NO
> Residential and Commercial Focus 110VAC power supply input.
> Duty Cycle: Continuous
> Battery backup integrated w/ (2) 7Ah 12VDC batteries T24S-CABLE 40' of cable for Primary/Secondary double gate
> Solar option available applications
> Warranty 4 years for residential, 3 years for commercial

Visit locks4gates.com to view the latest models and download spec sheets and installation manuals.
