INDUSTRIAL LOCK FOR SWING GATES

INDUSTRIAL LOCK

LAKQ U2
Industrial lock with aluminum housing and stainless steel mechanism. We recommend this lock as the
standard for your industrial gates. Handle depends on color: silver locks ship standard with the modern
aluminum handle pair and the black lock with the black ornamental handle pair. The latch gap required
is keeper dependent, but the standard and security keepers require a 1-1/4" latch gap.
• Easy left or right hand changing of the self-latching bolt
Powdercoated Black • Throw of 7/8" in 1 turn of the key
LAPQ10UBL- Fits: 3/8" - 1" Bar • 4-hole mounting with two hex head socket screws MIN. 3-3/4"
LAKQ30UBL- Fits: 1-1/4" Tube • Center distance between bolts: 2-3/8" 2 x Ø3/8"
3-9/16"
LAKQ40UBL- Fits: 1-1/2" - 2" Tube • Adjustment of the bolts up to 3/4" continuous 2 x Ø5/8"
LAKQ60UBL- Fits: 2-1/2" - 3" Tube without removing the lockbox 4 x Ø3/4"
13/16"

2-3/8"

6-5/16" 2-3/8” 5-9/16"

Powdercoated Silver 1-1/4"
LAPQ10USL- Fits: 3/8" - 1" Bar
LAKQ30USL- Fits: 1-1/4" Tube
LAKQ40USL- Fits: 1-1/2" - 2" Tube
LAKQ60USL- Fits: 2-1/2" - 3" Tube

GATE STOPS AND STRIKES ROUND POST ADAPTERS CHAINLINK
GATE LOCK KIT
Standard keep Security keep Adapter dapter Adapter Adapter
A
Must have Must have pla plate for plate for Kit includes: lock,
plate for te for
minimum minimum round posts round posts round posts security keeper, round
round posts
1-1/4" gap. 1-1/4" gap. Ø ≥ 1-3/8". Ø ≥ 2". Ø ≥ 2". post adapters, and
Ø ≥ 1-3/8".
Use where chainlink adapter
higher
security is
desired.

SAKLQFAL Aluminum SHKLQFAL Aluminum 3019LA For lock 3018LA For standard 6403 For security Powdercoated Black
SAKLQFBL Black SHKLQFBL Black keep keep LK30UBL

Electric Strike Gate Stop FREE EXIT OPTIONS For 1-3/8" gate
For profiles Recommended frame
greater than 2". gap 1/4". LK40UBL
Recommended For 1-5/8", 1-7/8"
gap 7/8". gate frame GATE HARDWARE
Powdercoated Silver
LK30USL
Push handle set
in aluminum A For 1-3/8" gate
Aluminum Push Barluminum Push Bar
frame
3006PUSH PUSHBAR LK40USL
SEE - Electric strike, fail SAKZ40BL
secure for LA locks The handle set ONLY fits the Push bar for easy opening of the For 1-5/8", 1-7/8"
SER - Electric strike, fail Industrial lock and allows it gate by a simple push. The Push gate frame
open for LA locks to be used in the following bar replaces the normal handle,
The strike is equipped applications: Safety Exit, Free operates the daybolt and can
with a double blocking Exit, Dead Latch, or Store Room quickly be installed on a new
system which supports Lock. The PUSH-set replaces the or existing Locinox LAKQ U2 or
1000 lb pulling-force. handle. LFKQ chassis.
Voltage 12V AC/DC.
A LL DIMENSIONS ARE APPR O XIM ATE .
