V-GROOVE ROLLING GATE SYSTEM

SURFACE MOUNTED V-GROOVE WHEELS - GALVANIZED

325V-100 5-3/4” (146mm)
• 4" wheel with 4-5/16” (110mm) 3/8” dia.
(9mm)
single bearing and
external surface
mount support 3-1/2” (90mm) 4-3/16” (106mm)
• 485lb capacity
per wheel
13/16”
1/4” (7.5mm) 1-1/2” (40mm)
3-7/8” dia. (98mm) (21mm)

5-3/4” (146mm) 1-1/2” (39mm)
326V-100 4-5/16” (110mm) Ø3/8” (9mm)
• 4" wheel with
double bearing and
external surface 3-1/2” (90mm) 4-3/16” (106mm)
mount support 3/8” (9.5mm)
• 890lb capacity 1-1/8”
per wheel (28mm)
3-7/8” dia. (98mm)

SLIDING GATE SYSTEMS

P
Equally distributed
weight
A LL DIMENSIONS ARE APPR O XIM ATE .
