MORTISE GATE LOCK KITS

MORTISE LOCK KITS WITH WELD BOX FOR
1½", 2" AND 2½" FRAMES

Mortise lock with 100% stainless steel mechanism. This model can be installed on steel and aluminum.
The massive stainless steel hook and adjustable latch bolt makes this a one of a kind lock. The
combination of the hook (dead bolt) with the SHKM keep provides a secure anchoring of your gate
while preventing the gate from being pried open as the dead bolt's "hook" locks into the keep's
anchoring plate. The latch gap required is keep dependent.

• Easy left or right changing of the self-latching daybolt
• Key-operated self-latching bolt, allows Free Exit application
• Adjustment of the latch bolt up to 3/4" continuous without removing the lock
• Stainless steel mechanism, hook, front plate and latch bolt
• Throw of the hook: 1-1/4"
• Center-distance cylinder <=> handles = 3-5/8"
• Hook in combination with the keep provides secure anchoring

HLB-15
KIT FOR 1-1/2" FRAMES INCLUDES:
• Lock (H-METAL-WB)
• 2 Stainless Steel Cover Plates (3020-HYB-A2)
• Stainless Steel Handles (3006I)
• Cylinder (3012-54-STD-VSZ, keyed different)
• Weld Box (HWLB)
• Keep (SF-KLALUMQF)
HLB-20

KIT FOR 2" FRAMES INCLUDES:
• Lock (H-METAL-WB)
• 2 Stainless Steel Cover Plates (3020-HYB-A2)
• Stainless Steel Handles (3006I-H)
• Cylinder (3012-60-STD-VSZ, keyed different)
• Weld Box (HWLB)
• Keep (SF-KLALUMQF)
HLB-25

KIT FOR 2-1/2" FRAMES INCLUDES:
• Lock (H-METAL-WB)
• 2 Stainless Steel Cover Plates (3020-HYB-A2)
• Stainless Steel Handles (3006I-H)
• Cylinder (3012-80-STD-VSZ, keyed different) ELECTRIC STRIKE FOR MORTISE LOCKS
• Weld Box (HWLB)
HARDWARE SEH-R - Electric strike, fail open for insert locks
GATE • Keep (SF-KLALUMQF) SEH-E - Electric strike, fail secure for insert locks Latch gap 1"

This electric strike is for swing gates using our
Mortise locks. The strike is equipped with a double
blocking system which supports 1000 lb (500Kg)
pulling-force. This keep is extremely strong and the
ideal solution for your access control installations.
The electric strike is available in a Fail Secure or Fail
Safe model.
• Extremely strong and
user-friendly design
• Easy left or right hand changing
• For profiles 2" and larger
• Voltage: 12 V AC/DC
• Water resistant, weatherproof
A LL DIMENSIONS ARE APPR O XIM ATE .
