SAMSON GATE CLOSER & TIGER GATE HINGE/CLOSER

ADJUSTABLE GATE CLOSER

SAMSON
The next generation of gate closers. Even easier to install and smoother
SAMSON 2 Self closing functioning. The final snap can easily be adjusted after installation by
For gates 36" to 78" max. gate turning the corresponding adjustment screw. The Samson can be posed
up to 330 lbs. weight in almost every situation thanks to the various brackets delivered with
330lbs the product. Due to the patented damping system, the operation of the
gate closer is unaffected by temperature changes.

• Opening angle up to 150° depending on the situation
• Adjustable closing speed & closing pressure
• New : Continuously adjustable final snap for a perfect closing
• Specially developed for outdoor use: industrial quality
• Closing speed unaffected by temperature changes
• Fast and easy fixing: Quick-Fix
• For left and right turning gates Watch video
• Tested at 500,000 cycles for installation
• Tested to -22° F instructions
CHAIN LINK ADAPTERS:
SB-4015 Ø 9/16” 1-3/16”
4" Post, 1-5/8" Gate Frame
SB-4020
4" Post, 1-7/8" Gate Frame 3-1/4” 1-3/4”
SB-3015 1-3/16” 1-3/8”
3" Post, 1-5/8" Gate Frame Ø 9/16”
SB-3020 2” 1-5/8” 2-13/16”
3" Post, 1-7/8" Gate Frame 3” . n
1-3/8”
M i
2”
1-3/8” 3-7/16”
4”

ADA compliant COMPACT GATE HINGE/CLOSER

TIGER
Hydraulic, self-closing, double bearing hinge with an 180° opening angle that
easily closes gates up to 165 lbs. Closing speed and final snap can be adjusted after
installation. Fast and easy installation with Quick-Fix.
• 180° self-closing hinge with patented hydraulic damping
• Compact design with high quality components Watch video
• Weatherproof aluminum housing designed for for installation
exterior use instructions
• Patented hydraulic damping - consistent closing
speed, regardless of temperature
• For left and right turning gates
• Fast and easy fixation with Quick-Fix bolts
• Installation gap 7/16" up to 1" (5/8" adjustability)
• 3/4" vertical adjustability 25/32” GATE HARDWARE
Self closing TIGER-9005 • ADA compliant (< 5 lbs; max 16 Nm) from 1-3/16”
max. gate gate widths of 3ft. or more 4-3/16”
weight Tiger hinge/closer
165lbs in black 2-3/8”
TIGER-ZILV PUMA hinge included
Tiger hinge/closer 2-3/4”
in silver CHAIN LINK ADAPTER: 10-7/16”
CLB-TIGER
1-7/8" to 4" Post
1-3/8" to 1-5/8" Ø1-7/8” Ø9/16” (6x)
Gate Frame
1-9/16”

4-3/16”
