LOCK FOR SLIDING GATES

SLIDING GATE LOCK

LSKZ U2
Slide gate lock for manual sliding gates with aluminum housing and stainless steel mechanism. The
key is used to override the lever action and secure the gate. The unique Twistfinger catch bolt and
self-correcting keep ensures latching of your sliding gate. Catch bolts are available to fit gate frame
profiles from 1-1/2" to 4" wide. Works with cantilever or rolling gate systems.
• Chassis, mechanism and Twistfinger in stainless steel
• Adjustable for horizontal or vertical mounting of the keep (catch bolt)
• Mounting with 2 hex head socket screws
• Innovative closing system
Powdercoated Black • Stainless steel collar around the Twistfinger 2 x Ø3/8"
2 x Ø5/8"
prevents cutting through the Twistfinger (catch bolt)
LSKZXXUBL • Standard with reinforced aluminum handle pair 2 x Ø7/8"
Powdercoated Silver
LSKZXXUSL

1-7/8"
Leonardo -
Mechanical
Code Lock 5-9/16"

1-1/4"
Powdercoated Black
LLKZXXVBL
3-13/16"
Powdercoated Silver MIN. 4-3/8"
LLKZXXVSL

CATCH BOLT SLIDING GATE KEEP ALUMINUM ADAPTER CASE FOR

7015-40 - Fits 1-1/2" gate frame SSKZ-QF SSKZ FOR FLAT PROFILES
7015-50 - Fits 2" gate frame O-SET
Stainless steel sliding keep for
7015-60 - Fits 2-1/2" gate frame hollow posts. Adapter for the SSKZ sliding gate keep.
7015-100 - Fits 4" gate frame • Keep in stainless steel for Can be used when mounting the keep
square profiles on flat profiles or if you want the keep
• Minimum profile size: surface-mounted.
3" wide
• Fast and easy installation:
Quick-fix
• The keep is 3/8" left/right
auto-adjustable for easy
and secure anchoring of
the lock-twistfinger
• The rubber stop prevents
damaging the gate frame

HARDWARE Adapter Illustrations show chainlink application. Parts shown include lock, round post adapters
GATE ROUND POST ADAPTER CHAINLINK ADAPTERS
and keep.
plate for
post has to
round posts Note: Latch
Ø ≥ 1-3/8".
be square
since SSKZ-QF
keep does not
fit on round
posts. CLH-CO
CLH For Leonardo mechanical
For standard lock chassis
3019LA - For lock code lock
A LL DIMENSIONS ARE APPR O XIM ATE .
