ELECTRO-MAGNETIC LOCK

ELECTRO MAGNETIC LOCK WITH OR

WITHOUT HANDLE

Magnetic lock with or without handle. Available in 2 versions. MAG3000/MAG-
MAG3000 with 660 lb. and MAG5000/MAGMAG-5000 with 1200 lb. of pulling force.
The aluminum powdercoated housing equipped with the unique Quick-Fix fixings
ensures a fast and nicely finished mounting. Eliminate time-consuming welding;
drilling 5 holes is enough to fix the lock. A two layer, protective coating guarantees
that our electro-magnetic locks are ready for years of worry free use outside.
• High holding force! Up to 1200 lb/500 kg
MAGMAG3000SL - Silver without Handle • 500h salt spray resistant!
MAGMAG3000BL - Black without Handle • Special two-layer protective coating developed for outdoor use
For mounting on square posts and gate profiles of • SGS Certified
1-1/2" to 3-1/8", 660 lbs. pulling force • Powdercoated aluminum casing
• Anti-residual magnetism kick-off system
MAGMAG5000SL - Silver without Handle • New anti-pry system: Raised edge on the magnet housing makes it impossible
MAGMAG5000BL - Black without Handle to put a crowbar between the magnet and the armature plate
For mounting on square posts and gate profiles of • No-handle version
1-1/2" to 3-1/8", 1200 lbs. pulling force • Fast and easy fixing by means of 5 holes with Quick-Fix
• Same center-distance as the standard Locinox keeps
MAG3000SL - Silver with Handle • MAG3000/MAGMAG3000: Minimal pulling force: 3000N (660 lbs)
MAG3000BL - Black with Handle • MAG5000/MAGMAG5000: Minimal pulling force: 5000N (1200 lbs)
For mounting on square posts and gate profiles of • Voltage: 12V/24V DC
1-1/2" to 3-1/8", 660 lbs. pulling force • Current MAG3000/MAGMAG3000: 500 mA / 12 V or 250 mA / 24 V
• Current MAG5000/MAGMAG5000: 460 mA / 12 V or 230 mA / 24 V
MAG5000SL - Silver with Handle
MAG5000BL - Black with Handle
For mounting on square posts and gate profiles of PULL HANDLE SET
1-1/2" to 3-1/8", 1200 lbs. pulling force
3006PULL.BL - Black This aluminum powder coated
handle set has an elegant design
3006PULL.SL - Silver and could be used in combination
with magnetic locks (e.g. if used
top/bottom), or any gate that needs
a sturdy and elegant pull handle
independent of the latching
mechanism.

SLIMSTONE ELECTRONIC KEYPAD

The SlimStone electronic keypad with integrated LED lighting, will work
with any low voltage setup. The SlimStone is guaranteed to work in all
weather conditions as it complies with IP68.
SLIMSTONE-9005 - Keypad in black
SAFETY POWER SUPPLY 110 V SLIMSTONE-ZILV - Keypad in silver

DC-POWER110-24V
HARDWARE electric devices on your gate. It fits nicely
GATE This power safety supply will help run

into the Locinox powerbox.
Safety DC power supply with 110V input
voltage and 24V / 25 W output.
• DIN Rail mount POWERBOX TRANSFORMER HOUSING
• Power: 25W PB-1-ZILV - Silver
• Primary voltage: 110V PB-1-9005 - Black
• Secondary voltage: 24V DC
(wire gauge 21 or thicker) • Waterproof tranformer box
• Black powder coated aluminum housing • Powder coated aluminum housing
• Robust control module: sealed for • Supplied with 2 gland nuts M20 and 2
superior humidity resistance stop plugs M16
in all climates • Designed with heat-dissipation fins at
the back
A LL DIMENSIONS ARE APPR O XIM ATE .
