CABLERAIL BY FEENEY®

Custom Cable Assemblies Quick-Connect cable fittings come in two types.
®
Projects with special installation conditions Fixed Ends (FE) are non-adjustable end termination fittings that have no tensioning capabilities.
or design considerations may require certain Therefore, each Fixed End must be paired with a Tension Adjustment Fitting.
styles of cable and fittings not addressed by Tension Adjustment Fittings (TAF) include Threaded Terminals, Turnbuckles and Adjusters that are
our CableRail Standard Cable Assemblies. To used to tighten the cable lines.
fulfill those specific design and function needs, Every cable assembly must have at least one Tension Adjustment Fitting.
we offer an assortment of cables, turnbuckles, Quick-Connect Quick-Connect
®
®
terminals, adjusters, and fixed ends for custom
assemblies. Fixed End Fittings Tension Adjustment Fittings
THE ORIGINAL QUICK-CONNECT SS QUICK-CONNECT THREADED TERMINAL
®
®
1x19 CONSTRUCTION CABLES Fits into a hole drilled in end post, and the lip rests Inserts through a drill hole in
19 individual wires twisted into a single, against the outside post face. the post and is secured and
semi-flexible strand. Excellent for 3146 For 1/8" Cable adjusted with a washer nut.
railings, fences, and trellises with 3147 For 3/16" Cable 9904 For 1/8" Cable
straight runs or slight bends. 3148 For 1/4" Cable 9804 For 3/16" Cable
Sold by the foot. QUICK-CONNECT FIXED SURFACE MOUNT QUICK-CONNECT
®
®
Attaches to the face of a wall or SURFACE MOUNT TURNBUCKLE
4140-1/8" 1/8" Cable post using screws or bolts. Attaches to the face of a wall
4117-3/16" 3/16" Cable 9903 For 1/8" Cable or post using screws or bolts.
9803 For 3/16" Cable 9902 For 1/8" Cable
QUICK-CONNECT LAG QUICK-CONNECT LAG SWIVEL TURNBUCKLE
®
®
Combines a lag thread hanger bolt Screws into the face of a wood post using a hanger bolt with
with a Quick-Connect® Body. Screws lag thread (included). Tension
into the face of a wood post. Can be paired adjusted by spinning the special
with any Tension Adjustment Fitting. swiveling turnbuckle body.
9905 For 1/8" Cable 9910 For 1/8" Cable
9810 For 3/16"" Cable
9805 For 3/16" Cable
STAINLESS & CABLE RAILING QUICK-CONNECT PIVOT QUICK-CONNECT PIVOT
®
®
SWIVEL TURNBUCKLE
Screws into the face of a wood post or wall
Screws into the face of a wood post or wall using
using a hanger bolt with lag thread (included).
180° pivoting allows for angled stair terminations.
adjusted by spinning the special swiveling turnbuckle
9915 For 1/8" Cable a hanger bolt with lag thread (included). Tension
9815 For 3/16" Cable body. 180° pivoting allows for angled stair terminations.
9916 For 1/8" Cable 9816 For 3/16" Cable
Cable accessories for metal and wood applications
CABLERAIL TENSIONING TOOL CABLE CUTTERS
Tensioning Tool includes the 1/8-in. diameter For shearing excess cable.
cable adapter head. Sold 1 per package Sold 1 per package.
6005-pkg 2972-pkg For cable up to 1/8",
8" long, coated
TENSIONING TOOL ADAPTER handles, hardened jaws
5071 For 3/16" and 1/4" cable 2971 For cable up
to 1/4",
13" long,
coated handles,
TENSION GAUGE hardened jaws
Designed for use on applications using
1/8, 3/16, and 1/4 inch sized cables with
1x19 construction. Sold 1 per package
6004-pkg FEENEY STEELRENEWAL™ + STEELPROTECT™ COMBO
Stainless Steel Cleaner and Protectant Combination Pack.
Sold 1 kit per package
Kit contains:
CABLE LACING NEEDLE • 1 Bottle Feeney SteelRenewal™ cleaner (100 ml.)
For quickly lacing cable ends through posts • 1 Bottle Feeney SteelProtect™ protectant (100 ml.)
without snagging. 4-1/2" long. Resuable. • Applicator brush for cleaner
Sold 1 per package. • Applicator sponge for protectant
3221-pkg For 1/8" cable • Protection gloves
3222-pkg For 3/16" cable 5064-pkg
3223-pkg For 1/4" cable
