CABLERAIL BY FEENEY®

Cable accessories for metal and wood applications

STAINLESS PROTECTOR SLEEVES (wood posts only) STAINLESS END CAPS
ASSEMBLY MODEL* ®
LENGTHS For protecting corner and stairway transition posts from Decorative option for covering and finishing Quick Connect SS
®
5' 6305-pkg cable abrasion. Sold 10 per package fittings and Snug-Grip Washer Nuts. Sold 4 per package.
10' 6310-pkg 3210-pkg 1/4"OD x 7/8"long, 3372-pkg Dome Style, 3/4"OD x 3/8"H
15' 6315-pkg (fits 1/4" diameter drill holes) 3373-pkg Crown Style, 3/4"OD x 3/8"H
20' 6320-pkg 3374-pkg Chamfer Style, 3/4"OD x 3/8"H
25' 6325-pkg STAINLESS BEVELED WASHERS
30' 6330-pkg For providing a flat bearing surface when
35' 6335-pkg at taching fittings at angled stair terminations.
40' 6340-pkg For 1/8" Cable DOME CROWN CHAMFER
45' 6345-pkg Sold 4 per package.
50' 6350-pkg 3799-pkg For 1/8" Threaded Terminal (3/4"OD x 9/32"ID)
55' 6355-pkg 3792-pkg For 1/8" Quick-Connect SS (3/4"OD x 3/8"ID) COLORED END CAPS (POLYETHYLENE) Decorative option for
®
®
60' 6360-pkg For 3/16" Cable covering and finishing Quick-Connect SS fittings and
®
65' 6365-pkg Sold 4 per package. Snug-Grip Washer Nuts.
70' 6370-pkg 3799-pkg For 3/16" Threaded Terminal (3/4"OD x 9/32"ID) Sold 10 per package.
7071-pkg Black, 3/4"OD x 3/8"H
*With 7½" terminal for wood posts
Sold Individually 7072-pkg White, 3/4"OD x 3/8"H
3798 For 3/16" Quick-Connect SS (3/4" OD x 9/16" ID) 7073-pkg Brown, 3/4"OD x 3/8"H
®
ASSEMBLY MODEL* 7074-pkg Gray, 3/4"OD x 3/8"H
LENGTHS For 1/4" Cable
5' 6805-pkg Sold 4 per package. ®
10' 6810-pkg 3792-pkg For 1/4" Threaded Terminal (3/4"OD x 3/8"ID) QUICK-CONNECT RELEASE TOOL ®
15' 6815-pkg Sold Individually For temporarily releasing the jaws of the Quick-Connect SS fitting to STAINLESS & CABLE RAILING
®
20' 6820-pkg 3798 For 1/4" Quick-Connect SS (3/4" OD x 9/16" ID) remove or adjust the position. Reusable.
Sold 1 per package.
25' 6825-pkg 3128-pkg For 1/8" Quick-Connect ®
30' 6830-pkg RUBBER GROMMET FOR 1/8" CABLE 3158-pkg For 3/16" Quick-Connect ®
35' 6835-pkg For eliminating direct contact of dissimilar metals
40' 6840-pkg to minimize electrolysis when attaching cables and
45' 6845-pkg fittings to metal posts in areas with salt air or similar
50' 6850-pkg harsh elements
55' 6855-pkg For 1/8" Cable
60' 6860-pkg 3213 1/4" OD x 3/16" groove, 7/16" flange
65' 6865-pkg
70' 6870-pkg
*With 7½" terminal for wood posts
ISOLATION BUSHINGS
For eliminating direct contact of dissimilar
metals to minimize electrolysis when attaching
cables and fittings to metal posts in areas with
salt air or similar harsh elements.
Part # Used On Size Hole Ø
For 1/8" Cable
1100 1/8" Quick-Connect®SS 3/8" ID x 15/32" OD, 11/16" flange 15/32"
1101 1/8" Cable 3/16" ID x 1/4" OD, 3/8" flange 1/4"
1102 1/8" Threaded Terminal 1/4" ID x 5/16" OD, 1/2" flange 5/16"
For 3/16" Cable
1103 3/16" Quick-Connect®SS 35/64" ID x 5/8" OD, 55/64" flange 5/8"
1102 3/16" Cable 1/4" ID x 5/16" OD, 1/2" flange 5/16"
1100 3/16" Threaded Terminal 3/8" ID x 15/32" OD, 11/16" flange 15/32"
For 1/4" Cable
1103 1/4" Quick-Connect®SS 35/64" ID x 5/8" OD, 55/64" flange 5/8"
1104 1/4" Cable 9/32" ID x 23/64" OD, 19/32" flange 23/64"
1105 1/4" Threaded Terminal 7/16" ID x 17/32" OD, 3/4" flange 17/32"
