SWING GATE OPERATORS

SUB UNDERGROUND SWING GATE OPERATOR

Underground hydraulic operator for swing gates up to 1,750 Lbs and 12 Ft
SUB UL

TECHNICAL FEATURES
> Capacity: 1750 lbs and 12 Ft
> Cycle Time: 14 seconds
> Motor: 24 VDC & 110VAC options
> Drive: Hydraulic SUB operators
> Power Supply: 120 VAC, 60 Hz, Single Phase are sold a la carte.
> Radio Controls: 433MHz Rolling Code (integrated)
> Weight: 58 lbs
USAGE
> Residential Focus
> Duty Cycle: 500 cycles/day
> In ground installation eliminates footprint
> Battery backup & Solar available on 24VDC model
> Warranty 2 years from install date

SUB R 120V UL In Ground Operator SUB BT 24V In Ground Operator
– 120VAC Motor, w/slowdown – 24VDC Motor, no slowdown
– No battery backup – Battery backup option
– MET Listed for UL325 – Not UL Compliant
P930012 00007 SUB R UL/CSA DX P930123 00001 SUB BT 2B
Motor on right hand side of driveway from inside the Operator can be used for both left and right hand
property. installations

P930012 00008 SUB R UL/CSA SX Controller Options
Motor on left hand side of driveway from inside the KTHALIAUL-SE Controller
property. Thalia control board w/

Controller Options integrated receiver, 10" x 12"
fiberglass enclosure, pre-wired.
The Rigel 6 controller boards include a built-in receiver,
24/7 timer, power outlet, and test button.
KTHALIAUL-LEB Controller
RIGEL6UL-LE Thalia control board w/
Controller integrated receiver, 12" x 14"
Larger 16" x fiberglass enclosure, pre-wired.
18" Fiberglass Includes battery backup with (2)
RIGEL6UL-SE Controller enclosure, pre- 12V, 9AH batteries, 110V outlet.
Standard 10" x 12" wired, 120V, Foundation Box
Fiberglass enclosure, w/Rigel 6 board,
pre-wired, 120V, pre-wired for loop Bearing Foundation Cases allow maintenance to be
w/Rigel 6 board detectors carried out without disassembling the gate.
Foundation Boxes N733480 00001 - FCS BOX
Bearing Foundation Cases allow maintenance to be Used for right or left hand
carried out without disassembling the gate. installations
N733066 00001 - CPS DX (Right Hand)
N733066 00002 - CPS SX (Left Hand)

Visit locks4gates.com to view the latest models and download spec sheets and installation manuals.
