Page 464 - CATALOG

SWING GATE OPERATORS

IGEA SWING GATE OPERATOR

Electromechanical operator for column mounted swing gates
up to 550 Lbs and 10 Ft
IGEA BT UL

TECHNICAL FEATURES IGEA Standard Kits include Thalia control board w/
> Capacity: 550 lbs and 10 Ft integrated receiver, 10" x 12" fiberglass enclosure, 2 Mittos
> Cycle Time: 15 seconds remotes
> Motor: 24 VDC
> Drive: Column mounted articulated arm KIGEAUL-S-SE
> Power Supply: 120 VAC, 60 Hz, Single Phase SINGLE IGEA BT Operator, Controller, 10ft of wire, 1 polarized
> Radio Controls: 433MHz Rolling Code (integrated) reflective photocell (KIRPOLAPHOT001)
> Weight: 35 lbs KIGEAUL-D-SE
> MET Listed for UL, 325, Door, Drapery, Gate, DUAL IGEA BT Operators, One Controller, 35ft of wire,
Louver & Window Operator Systems 1 polarized thru-beam Compacta photocell
> Mechanical Limit Switches
USAGE IGEA Battery Backup Kits includes Thalia control board w/
> Residential Focus integrated receiver, 12" x 14" fiberglass enclosure w/115V
> Column or Post Mounted Outlet, 2-9AH batteries, 2 Mittos remotes
> Designed for easy & simple installation KIGEAUL-S-LE
> Duty Cycle: 100 cycles/day SINGLE IGEA BT Operator, Controller, 10ft of wire, 1 polarized
> Small footprint reflective photocell (KIRPOLAPHOT001)
> Battery backup available KIGEAUL-D-LE
> Solar option available DUAL IGEA BT Operators, One Controller, 35ft of wire,
> Warranty 2 years from install date 1 polarized thru-beam Compacta photocell

E5 Swing Gate Operator Electromechanical operator for column mounted
swing gates up to 220 Lbs and 6 Ft
P930027 00003 E5 BT A12 P930027 00001 E5 BT A18
up to 175 Lbs and 4 Ft up to 220 Lbs and 6 Ft

TECHNICAL FEATURES E5 operators are sold a la carte. One or two actuators, a
> Capacity: 175 lbs and 4 Ft / 220 lbs and 6 Ft controller, and accessories as needed.
> Cycle Time: 4.5 - 6.5 seconds / 14 seconds Includes Articulated
> Motor: 24 VDC Arm (N734921)
> Drive: Column mounted articulated arm
> Power Supply: 120 VAC, 60 Hz, Single Phase
> Radio Controls: 433MHz Rolling Code (integrated)
> Weight: 20 lbs KTHALIAUL-SE Controller
> Mechanical Limit Switches Thalia control board w/
USAGE integrated receiver, 10" x 12"
> Residential Focus fiberglass enclosure, pre-wired.
> Pedestrian gates or doors
> Unique Push & Go function allows the gate to be
opened by a simple push of the hand
> Non-Locking - Mag lock recommended
> Duty Cycle: 110 cycles/day
> Small footprint KTHALIAUL-LEB Controller
> Battery backup available Thalia control board w/ N735057
> Solar option available integrated receiver, 12" x 14"
> Optional sliding arm available for constraints such fiberglass enclosure, pre-wired. Sliding Arm for E5 BT A12
as walls and obstacles Includes battery backup with (2) Used for restricted space
> Warranty 2 years from install date 12V, 9AH batteries, 110V outlet. applications.
