Page 408 - CATALOG

GATE CLOSERS

TB SERIES 200 / 400 / 600 GATE CLOSERS

Lockey Hydraulic Gate Closers TB200/400/600, also known as a Pedestrian Gate Closer,
does not slam gates shut. It firmly and quietly pushes gates closed, making it ideal
Self closing for use with magnetic locks and other latching devices. The closing speed is pre-set
max. gate to provide a controlled close of 8 seconds or more, depending upon the weight of
weight
50-250lbs the gate and quality of hinges. With this closer there is no risk of maladjustment or
tampering with the speed adjustment after it is fitted.
Each gate closer includes instructions, mounting brackets and fitting bar. As with most
gate closers, it is advisable to install a mechanical stop to restrict the gate opening
angle** to avoid damage to the closer. (NON FIRE RATED)
• Easy to install
TB200BL - Light Duty Closer • Installs on side, top, middle or bottom of right or left hand gates
in Black • Mounts on opening side of gate, pushing the gate closed
TB200SS - Light Duty Closer in • Maximum opening angle of 110 degrees** (LockeyUSA® recommends use of a
Stainless Steel mechanical stop to restrict opening angle)
• Closers available in black and stainless steel finishes
TB400BL - Medium Duty Closer Technical Overview
in Black
TB400SS - Medium Duty Closer TB200 (Light Duty) TB400 (Medium Duty) TB600 (Heavy Duty)
in Stainless Steel Max. Gate Weight 50-125 lbs. 75-175 lbs. 150-250 lbs.
Max. Gate Width 36-52 in. 40-64 in. 44-72 in.
TB600BL - Heavy Duty Closer Max. Opening Angle 110 degrees** 110 degrees** 110 degrees**
in Black Type of Gate Material Vinyl, Steel, Wood Vinyl, Steel, Wood Vinyl, Steel, Wood
TB600SS - Heavy Duty Closer
in Stainless Steel Closing/Latch Method Hydraulic/Nitrogen Gas Hydraulic/Nitrogen Gas Hydraulic/Nitrogen Gas
Material Steel/Stainless Steel Steel/Stainless Steel Steel/Stainless Steel
Color Black or Stainless Steel Black or Stainless Steel Black or Stainless Steel
Hinge Arrangements In-line or Offset In-line or Offset In-line or Offset
Opening Pressure Approx. 3-7 lbs. Approx. 6-12 lbs. Approx. 8-18 lbs.
CHAINLINK MOUNTING KIT COMPATIBLE
WITH TB200/400/600

• Works on Fence Posts 2" - 2-7/8"
Includes
- One Post Bracket
- One U-Bolt
- Two Machine Screws
TB-LINX - Steel - Four Lock Nuts

SHOTGUN GATE
SPRINGS FOR WOOD GATES CLOSER
• Safe & easy installation – No special for gates weighing up to 250 lbs.
tools required
HARDWARE cycles Black Closer
GATE • Long life – Tested to over 1 million SHOTGUN-BK

• Safety – Tension adjustable to ensure SHOTGUN-SC
gate closes long after installation FEATURES: Satin Chrome Closer
• Pneumatic Design - No oil leaks
• Easy to adjust – Springs include
stickers to assist consumer in adjusting • Double Barrel Closing Power Self closing
max. gate
tension • Adjustable Closing Speed weight
• Maximum Opening of 90° 250lbs
11" Spring 14" Spring • Anti-slam Technology
410001 410002
• Replaceable pneumatic “Shotgun” barrels for extended
lifetime performance and easy maintenance
Gate stop is required to prevent gate from opening more than 90°.
A LL DIMENSIONS ARE APPR O XIM ATE .
