REGENCY RAILINGS WINDSOR I PANELS U.S. PATENT #7,594,643 B2
Windsor©

Windsor I hoops are 5/8" square bar and the center bar of piece C & D is 3/8" round.

Windsor I is sold in sets and includes one hoop, two collars, two fleur de lis,
two threaded rods, and one center medallion.
IRON & STEEL RAILINGS If powdercoating is an option, the panels must be sandblasted and cleaned first and then powder coated.
All railing panels come painted textured black. The panels can be painted over.

Available in steel and aluminum (see page 224).
PIECE A PIECE C PIECE B PIECE D
IS SUPPLIED WITH A USE WITH PIECE A IS SUPPLIED WITH A USE WITH PIECE B
STRAIGHT OR ANGLED STRAIGHT OR ANGLED
COLLAR. PLEASE COLLAR. PLEASE
CHOOSE ITEM FOR YOUR CHOOSE ITEM FOR YOUR
APPLICATION. APPLICATION.

Collar
See page
109 for more
examples.

STEEL PIECE A & C STEEL PIECE B & D ALUMINUM PIECE A & C ALUMINUM PIECE B & D
For straight applications WIN A1C-0 WIN B1D-0 WIN A1AC-0 WIN B1AD-0
Fits angles 21° to 27° WIN A1C-24 WIN B1D-24 WIN A1AC-24 WIN B1AD-24
Fits angles 28° to 34° WIN A1C-31 WIN B1D-31 WIN A1AC-31 WIN B1AD-31
Fits angles 35° to 42° WIN A1C-39 WIN B1D-39 WIN A1AC-39 WIN B1AD-39
Fits angles 43° to 49° WIN A1C-46 WIN B1D-46 WIN A1AC-46 WIN B1AD-46

HOOP ONLY
WIN A1 Piece A in Steel
WIN A1A Piece A in Aluminum

Close up of WIN B1 Piece B in Steel
aluminum WIN B1A Piece B in Aluminum
collar.

A LL DIMENSIONS ARE APPR O XIM ATE .
