REGENCY RAILINGS REGENCY PANELS

Regency panels include a 1/2" sq. post at 3" or 4" tall depending on the panel chosen.
The scroll design is made of 3/8" x 1" flat bar. The side bars are 1" square tube.

PIECE C PIECE C PIECE D PIECE E PIECE F
FITS ALL ANGLES FITS ALL ANGLES FITS ALL ANGLES FITS ALL ANGLES FITS LEVEL
UP TO 48° UP TO 48° & LEVEL BALCONY BALCONY OR IRON & STEEL
STRAIGHT RAIL RAILINGS
1/2" W x 1/2" D 1/2" SQUARE
3/8" W x 1" D POST
IRON 1/2" W x 1/2" D 1/2"
18-1/2" 15" 7" FLATTENED
15" 18-1/2"
3/8" W x 1" D 3/8" W x 1" D 3/8" W x 1/2" D
IRON
IRON 3/8" W x 1/2" D
1/2" W x 1/2" D
1/2" SQUARE 3/8" W x 1" D
10" 42" 16-1/4"
10" 27-1/2" 42" 16-1/4" 3/8" W x 1" D
TOP VIEW FLAT TOP VIEW FLAT
RE C-1 RE C-1 5-1/2" 7"
1/2" W x 1/2" D
3/8" W x 1" D 5"
IRON 5"
18-1/2" 18-1/2" 15" 2-1/2"
15" TOP VIEW FLAT TOP VIEW FLAT
3/8" W x 1" D
IRON
1/2" W x 1/2" D RE D RE E RE F
10" 10"
TOP VIEW TOP VIEW

RE C-2 RE C-2 3/4" x 1" 3/4" x 1"
FLAT IRON FLAT IRON
For all radius For all radius 3/4" x 1"
from 30 inches to 20 feet from 30 inches to 20 feet FLAT IRON

1/2" W x 1/2" D 1/2" x 1/2" 1/2" x 1/2" 1/2" x 1/2"
3/8" W x 1" D SQUARE IRON SQUARE IRON SQUARE IRON
IRON
18-1/2" 18-1/2" 15"
15"
3/8" W x 1" D
IRON
1/2" W x 1/2" D
4-1/2" RADIUS 4-1/2" RADIUS
10" 10"
TOP VIEW TOP VIEW
18"
RE C-3 RE C-3 RE TERM-L RE TERM-FLAT RE TERM-R
For all radius For all radius
from 30 inches to 20 feet from 30 inches to 20 feet

A LL DIMENSIONS ARE APPR O XIM ATE .
