ROPE TWISTS, FULLY TWISTED & HOT PIERCED BARS

SOLID BAR ROPE TWIST
sold in 9'4" Lengths
COMPOSITION OF
FOUR STRAND
11/86 5/8" 11/88 1" 11/90 1-1/2" ROPE TWIST IRON & STEEL RAILINGS
11/87 3/4" 11/89 1-1/4" diameter
across strands
Our rope twists have a variety of applications. They can be used as decorative 5/8" 4 x 1/4"
handrail, foot rail, trip rail and also provide a stunning effect when used in furniture. 3/4" 4 x 5/16"
1" 4 x 3/8"
FULLY TWISTED BARS 1-1/4" 4 x 1/2"
sold in 10' Lengths 1-1/2" 4 x 5/8"

11/34 1/4" sq. 11/37 1/2" sq. 11/40 1" sq.
11/35 5/16" sq. 11/38 5/8" sq. 11/41 1-1/4" sq.
11/36 3/8" sq. 11/39 3/4" sq.

PUNCHED BAR and PUNCHED CHANNEL
Custom made to your specifications.
Please specify dimensions of A, B, C and provide material size (required).

Punched Bar with
Square Holes

Punched Bar with
Round Holes

HOT PIERCED BARS

607/1 606/2 42/9/US 42/2/US
9/16" dia. 5/8" dia. 5/8" sq. 5/8" dia.
Pitch = 5-1/2" Pitch = 5-7/8" Pitch = 5-15/16" Pitch = 5-15/16"
1-3/32" x 9/16" holes 5/8" holes 5/8" sq. holes 5/8" round holes
Holes per bar 14 Holes per bar 13 Holes per bar 17 Holes per bar 17
78-3/4" long 78-3/4" long

A LL DIMENSIONS ARE APPR O XIM ATE .
