HANDRAIL BRACKETS

2 1 /4" 2 1 /4"
c 1 1 /2" c 1 1 /2"
C'sunk for C'sunk for
a a
1 /4" Screw 1 /4" Screw
b b
IRON & STEEL RAILINGS
Clear Hole for Clear Hole for
3 /8" Mounting Bolt 3 /8" Mounting Bolt
2 3 /4" 2 3 /4"
Round Saddle Bracket with One Mounting Hole Flat Saddle* Bracket with One Mounting Hole
SATIN SATIN SATIN SATIN
A B C STAINLESS BRONZE A B C STAINLESS BRONZE
1-1/2" 2-15/16" 2-1/2" 1815 1813 1-1/2" 2-15/16" 2-1/2" 1815F 1813F
1-1/2" 2-15/16" 3-1/4" 1816 1814 1-1/2" 2-15/16" 3-1/4" 1816F 1814F
2 7 /16"
1 3 /4 "
a c
1 /4" 2 1 /4"
1" 1 1 /2"
1 5 /8" 5 /16"
1 1 /2"
3"
Wall Mount Handrail Bracket 3 /8-16 3 1 /8"
Tapped Hole
Rotates to any angle. Single tapped 3/8"-16 hole.
Universal Saddle Fits Round and Flat Materials
SATIN SATIN with One 3/8-16 Tapped Hole
C ALUMINUM BRASS
2-3/8" MB2251W MB4251W Saddle Holes are clear for 1/4" screws.
2-7/8" MB2301W MB4301W C MALLEABLEIRON SATIN ALUMINUM
2 7 /16" 2-1/2" 4591 4592
1 3 /4 "
a 3-1/4" 4581 4582
1 /4"
1 5 /8"

Brass Handrail Brackets
3"
Wall Mount Handrail Bracket
Rotates to any angle. Single tapped 3/8"-16 hole.
SATIN
C STAINLESS
2-3/4" MB250W
3-1/2" MB3300W
00-301 00-310
ITEM # TUBING CP D ITEM # CP D
00-301/1-1/2 1-1/2" 2-1/2" 2-1/2" 00-310 2-1/4" 2-1/2"
00-301/2 2" 2-1/2" 2-1/2"

Wall Mount Handrail Bracket for Square Tube
AISI SATIN STAINLESS Steel Handrail Bracket with
304 13.0111.000.12 Polished & Lacquered Brass Rosette

Wall Mount Handrail Bracket
SATIN SML31 SML32
FITS AISI STAINLESS Backplate: 3-1/2" dia.
1-1/4" Pipe 304 13.0111.038.12 Backplate: 2-15/16" dia. Bracket Arm: 9/16"
1-1/2" OD Round Tubing Bracket Arm: 5/8"
Clearance from wall: 3-3/8" Clearance from wall: 3-3/8"
1-1/2" Pipe 304 13.0111.050.12
2" OD Round Tubing A LL DIMENSIONS ARE APPR O XIM ATE .
