FLANGES AND MOUNTING

NOTES:
• All fittings are supplied with necessary
hardware for installation FITTINGS ARE SUPPLIED
• Mount brackets to stud in wall. WITH SELF-DRILLING /
• Maximum spacing between brackets – 4 feet. SELF-TAPPING
• Consult local codes for rail height and other HARDWARE
requirements.

500 Wall Flange 510 Wall Flange 511/531 Cut Flange
ITEM # TUBING D H ITEM # TUBING D H ITEM # TUBING D W
00-500/1 1" 2" 7/8" 00-510/1-1/2 1-1/2" 3" 1-1/4" 00-511/1-1/2 1-1/2" 3" 2"
00-531/2 2" 4" 2-1/2"

515/535 Angle Flange 530 Wall Flange 532 Floor Flange
ITEM # TUBING D CP ITEM # TUBING D H ITEM # TUBING D H
00-515/1-1/2 1-1/2" 3" 2-1/8" 00-530/2 2" 4" 1-1/4" 00-532/2 2" 5" 1-3/8"
00-535/2 2" 4" 2-1/8"

BRASS RAILINGS

512 Floor Flange 533 Adjustable Flange 540 Canopy
ITEM # TUBING D H ITEM # TUBING D H ITEM # TUBING D-1 H-1
00-512/1-1/2 1-1/2" 4" 1-1/4" 00-533/2 2" 4" 2-9/16" 00-540/1-1/2 1-1/2" 4" 1"
00-540/2 2" 5" 1"

545
541 Steel Flange Floor Socket w/Cap
ITEM # TUBING D-2 H-2 ITEM # TUBING D H
20-541/1-1/2 1-1/2" 3-1/2" 1-3/8" 00-545/2 2" 4-7/8" 4-1/2"
20-541/2 2" 4-1/2" 1-1/2"

A LL DIMENSIONS ARE APPR O XIM ATE .
