CANTILEVER SLIDING GATE HARDWARE

Model CGS-500.8M CGS-500.8P CGS-500.8G
Opening range: Up to 23 ft. Up to 26 ft. Up to 52 ft.
Weight: Up to 1100 lbs. Up to 1760 lbs. Up to 2645 lbs.

CARRIAGES CGS-500.8M CGS-500.8P CGS-500.8G
Small Primary/Secondary Large Primary/Secondary Grande Primary/Secondary
8-Wheel Carriage Set 8-Wheel Carriage Set 8-Wheel Carriage Set
• Driven Primary Carriage • Driven Primary Carriage • Driven Primary Carriage
• Secondary Carriage • Secondary Carriage • Secondary Carriage

TRACK CGS-345M CGS-345P CGS-345G
Small, galvanized steel Large, galvanized steel Grande, galvanized steel
19'8" or 9'10" lengths 19'8" or 9'10" lengths 19'8" or 9'10" lengths
RACK CG-50M CG-50P CG-50G
4'11'' Gear Rack 4'11'' Gear Rack 3'4'' Gear Rack
w/Mounting Screws w/Mounting Screws w/Mounting Screws

TEMPLATE CG-55M CG-55P CG-55G
Gear rack centering device Gear rack centering device Gear rack centering device
Set of 2 pieces Set of 2 pieces Set of 2 pieces
Installation tool to center and Installation tool to center and Installation tool to center and
align gear rack in track align gear rack in track align gear rack in track

ADAPTER CG-58 CG-58 CG-58G
Drive Shaft Coupling Drive Shaft Coupling Drive Shaft Coupling

TYPICAL
ACCESSORIES
2x CGS-347M CGS-347P CGS-347G
End Wheel for UL325 Compliance End Wheel for UL325 Compliance End Wheel for UL325 Compliance

1x CGS-346M CGS-346P CGS-346G
Bottom End Cup Bottom End Cup Bottom End Cup
CG-15M CG-15P CG-15G
2x
Adjustable mounting bracket Adjustable mounting bracket Adjustable mounting bracket

1x CG-30M CG-30M CG-30M
Gate receiver, 2" - 3" frame Gate receiver, 2" - 3" frame Gate receiver, 2" - 3" frame
12x CG-348-M16 CG-348-M16 CG-348-M20
Threaded J-bolt for mounting Threaded J-bolt for mounting Threaded J-bolt for mounting
carriages. carriages. carriages.
2x CG-05P CG-05P CG-05G
Foundation plate for carriage Foundation plate for carriage Foundation plate for carriage
TOP GUIDE OPTIONS Galvanized & SIDE MOUNT GUIDE OPTIONS
Adjustable Guiding Plate with roller covers Aluminum Guide CG-252
to avoid pinch points. Rail Single Roller, 1½" dia. 230-40
CG-254
This roller only works
Nylon
SLIDING GATE SYSTEMS 256-220 Galvanized 1½" U-Channel, 9'10" with CG-254 253-40 Replacement
Roller
RG-387-19.68FT
1½" dia.
Galvanized 1¼" U-Channel, 19'8"
Galvanized 1¼" U-Channel, 9'10"
1¼" dia.
255-220-C For up to 3" frames RG-387-9.84FT 258-30 10" Side Roller
For up to 2⅜" frame 256-300 CG-237-20FT / CG-237-10FT Double Roller 2" clearance
1¼" dia.
Use 2 per gate min.
Aluminum 1½" U-Channel, 20' / 10'
For up to 4½" frames
USE FOR GATES WITH AN ARCHED TOP OR PROTRUDING PICKETS
