DECORATIVE FLAT & CONVEX BARS

Perfect for handrails, balconies and balustrade rails, our flat bar comes in a range of designs.
Match up with our end scrolls and sweeps.

IRON & STEEL RAILINGS WAVY BAR DESIGN PATTERNED FLAT BAR–Supplied in 9'10" lengths Shown: 114/5

4/4
1-1/2" wide x 5/16" thick

EGYPTIAN

6/7
1-1/2" wide x 5/16" thick

TREE BARK DESIGN
4/2
1-1/2" wide x 5/16" thick

Supplied 118" long

1834/2 1834/5 118/29 114/4 114/5 114/8 114/12
1-7/32" wide 1-1/4" wide 1-9/16" wide 1-9/16" wide 1-9/16" wide 1-9/16" wide 1-9/16" wide
3/16" thick 3/8" thick 1/8" thick 5/16" thick 5/16" thick 5/16" thick 5/16" thick
HALF OVAL HANDRAIL HAMMERED FLAT BAR
Supplied in 19'8" lengths Supplied in 19'8" lengths

4435
2-1/8" wide 4/14-20FT
3/4" high 1-1/2" x 5/16"

VOLUTE
4435V
5-1/2" long
and 2-1/4" tall
Supplied in CONVEX HANDRAIL & FITTINGS Y
19'8" lengths Y
Y

Lamb's Corner X
Tongue Y Bend
X 4/6K X
4/6LT
X =4-3/4" X Volute X = 8-1/8"
4/6-20FT Y = 5-3/4" 4/6V Y = 3-1/2" Terminal End
2" x 1/2", X = 2-1/2" 4/6E
Convex handrail, Y = -5-5/8" X = 3-11/16"
flat base A LL DIMENSIONS ARE APPR O XIM ATE . Y =2"
