ALUMINUM SCROLLS & SPLIT SHOES

SCROLLS

770/5 770/4 1867/7 770/6 770/8 770/7 770/10
1/2" x 1/4" matl. 1/2" x 1/4" matl. 1/2" x 1/4" matl. 1/2" x 1/4" matl. 1/2" x 1/4" matl. 1/2" x 1/4" matl. 1/2" x 1/4" matl.
4¾" W x 14 ³/₁₆" H 4¾" W x 11⁷/₁₆" H 5½" W x 8¹⁵/₃₂" H 4⅛" W x 5⅞" H 2¹⁵/₁₆" W x 4¾" H 2¹⁵/₁₆" W x 4¹⁵/₁₆" H 2⅜" W x 4½" H

SPLIT SHOES ALUMINUM RAILINGS

DIE CAST ALUMINUM SPLIT SHOES-MARINE GRADE

Square Puzzle-Lock
Split Flange
Covers an area of 4" x 4"

ALSS-1-1/2 for 1½" 4" sq. base 1⅛" H
ALSS-2 for 2" 4¼" sq. base 1⅛" H
ALSS-2-1/2 for 2½" 5¼" sq. base 1⅛" H
26436 for 1½" ALSS-3 for 3" 5½" sq. base 1⅛" H
4⅜" sq. base ¾" H
26437 for 2" CAST ALUMINUM SPLIT SHOES
4⅜" sq. base ¾" H 245A-58 for ⅝" 1¹¹/₁₆" sq. base 1¼" H
245A-34 for ¾" 1¹¹/₁₆" sq. base 1⅜" H
245A-1 for 1" 2½" sq. base 1⅝" H
Puzzle-Lock 245A-114 for 1¼" 3" sq. base 1¾" H
Split Flange for 245A-112 for 1½" 3" sq. base 1⅝" H
Schedule 40 Pipe 245A-2 for 2" 3⅝" sq. base 2" H
245A-212 for 2½" 4½" sq. base
2¼" H
245A-3 for 3" 6¼" sq. base 2⅝" H
245A-4 for 4" 7" sq. base 3" H

SIMSHOE-A PLASTIC SPLIT-COVER STYLE SHOE!
While traditional cover shoes must be on the post before the baseplate
26412 for 1¼" Ø (O.D. 1.66") pipe is welded to it, Simshoe ™ allows you to put your shoes on last.
4⅜" Ø base ⅜" H SS1-3 for 1" 3⁹/₁₆" sq. base 2" H
26413 for 1½" Ø (O.D. 1.90") pipe SS114-3 for 1¼" 3⁹/₁₆" sq. base 2" H
4⅜" Ø base ⅜" H SS112-3 for 1½" 3⁹/₁₆" sq. base 2" H
SS112-4 for 1½" 4¾" sq. base 1⅞" H
SS2-4 for 2" 4¾" sq. base 1⅞" H
A LL DIMENSIONS ARE APPR O XIM ATE .
