FLANGES

TUBING IS ON BRASS FLANGES
PAGE 312

500 Wall Flange 510 Wall Flange 530 Wall Flange 511/531 Cut Flange
ITEM # TUBING D H ITEM # TUBING D H ITEM # TUBING D H ITEM # TUBING D W
00-500/1 1" 2" 7/8" 00-510/1-1/2 1-1/2" 3" 1-1/4" 00-530/2 2" 4" 1-1/4" 00-511/1-1/2 1-1/2" 3" 2"
ORNAMENTAL METALS
00-531/2 2" 4" 2-1/2"

532 Floor Flange 512 Floor Flange 533 Adjustable Flange
ITEM # TUBING D H ITEM # TUBING D H ITEM # TUBING D H
00-532/2 2" 5" 1-3/8" 00-512/1-1/2 1-1/2" 4" 1-1/4" 00-533/2 2" 4" 2-9/16"

Example
showing brass
tubing and
canopy over
steel flange

540 Canopy 541 Steel Flange* 545 Floor Socket w/Cap
ITEM # TUBING D-1 H-1 ITEM # TUBING D-2 H-2 ITEM # TUBING D H
00-540/1-1/2 1-1/2" 4" 1" 20-541/1-1/2 1-1/2" 3-1/2" 1-3/8" 00-545/2 2" 4-7/8" 4-1/2"
00-540/2 2" 5" 1" 20-541/2 2" 4-1/2" 1-1/2"
*Use with 540 Canopy
STAINLESS STEEL TUBING FLANGES
TUBING IS ON
FITTINGS ARE AVAILABLE IN A 304 SS 40-POLISHED • 304 SS 44-SATIN PAGE 302
316 SS 47-POLISHED • 316 SS 49-SATIN FINISH

510 Wall Flange 530 Wall Flange 532 Floor Flange 511/531 Cut Flange
ITEM # TUBING D H ITEM # TUBING D H ITEM # TUBING D H ITEM # TUBING D W
44-510/1-1/2 1-1/2" 3" 1-1/4" 47-530/2 2" 4" 1-1/4" 40-532/2 2" 5" 1-3/8" 40-511/1-1/2 1-1/2" 3" 2"
49-530/2 44-532/2 44-511/1-1/2
40-531/2 2" 4" 2-1/2"
44-531/2

540 Canopy 541 Steel Flange 545 Floor Socket w/Cap 544 Floor Socket w/Cap
ITEM # TUBING D-1 H-1 ITEM # TUBING D-2 H-2 ITEM # TUBING D H ITEM # TUBING D H
49-540/1-1/2 1-1/2" 4" 1-1/4" 20-541/1-1/2 1-1/2" 3-1/2" 1-3/8" 40-545/2 2" 4-7/8" 4-1/2" 40-544/2 2" 2-3/4" 4-1/2"
49-540/2 2" 5" 1-1/2" 20-541/2 2" 4-1/2" 1-1/2" 44-545/2 44-544/2
*Use with 540 Canopy
A LL DIMENSIONS ARE APPR O XIM ATE .
