FLANGES

PIPE FLANGES

Heavy Duty Weld Flange
4-3/8" diameter with four oval mounting holes, clear for 3/8"
bolts. May be used with or without a canopy flange. Heavy Base Plain Flange with Set Screw*
FOR USE WITH PIPE THICKNESS STEEL TYPE 304 PIPE OD STEEL ALUMINUM STAINLESS
SIZE
STAINLESS
DIAMETER
PIPE SIZE
ORNAMENTAL METALS 1-1/4" 1.66" 1/4" 1613HD 1613HD-S 1-1/2" 1.90" 1437 1477 1537
1529
1-1/4"
1.66"
1429
1469
1623HD 1623HD-S
1/4"
1.90"
1-1/2"
* 1/4"-20 set screw - not for structural use.
Canopy Flange
4-1/2" diameter, 18 gauge. Cover has clearance for 3/8" bolt Snap-On Cover Flange Base
heads. This canopy flange drops into place. Use epoxy or silicone 4-3/8" diameter base has four clear mounting holes for 3/8" bolts.
to affix to heavy duty weld flange..
PIPE COVER 3003 TYPE 304
PIPE COVER 3003 TYPE 304 SIZE OD DIAM. THICK. STEEL ALUMINUM STAINLESS
SIZE OD DIAM. HT. STEEL ALUMINUM STAINLESS 1-1/4" 1.66" 4-3/8" .25" 2065B 2066B 2067B*
1-1/4" 1.66" 4-1/2" 1" 2065 2066 2067 1-1/2" 1.90" 4-3/8" .25" 2075B 2076B 2077B*
1-1/2" 1.90" 4-1/2" 1" 2075 2076 2077
* Thickness = .188".

Plain Flange Flange with Four Holes
PIPE PIPE
SIZE OD STEEL ALUMINUM STAINLESS SIZE OD STEEL ALUMINUM
1-1/4" 1.66" 1610 1630 1610-S 1-1/4" 1.66" 1613 1633
1-1/2" 1.90" 1620 1640 1620-S 1-1/2" 1.90" 1623 1643

PLASTIC SIMSHOE

Puzzle-Lock Split Flange for Schedule 40 Pipe

TUBE
SIZE OD HEIGHT BASE SIZE STEEL ALUMINUM
1-1/4" 1.66" 3/8" 4-3/8" Ø 26402 26412 DT-112R for 1½" dia. Tubing
1-1/2" 1.90" 3/8" 4-3/8" Ø 26403 26413 SP-114R for 1¼" dia. Standard Pipe
SP-112R for 1½" dia. Standard Pipe

A LL DIMENSIONS ARE APPR O XIM ATE .
