Page 152 - CATALOG

PICKET COLLARS FOR SQUARE BAR

All measurements height x width.

STEEL

89/21-12mm
1-292 1-292-2 89/21-16mm 89/22 89/23 89/24 89/31
ORNAMENTAL METALS ⅞" x 1⁹/₁₆" ⅞" x 1⁹/₁₆" ⅝" x 1⁵/₁₆" for ¾" sq. bar for 1" sq. bar for 1¼" sq. bar for 1½" sq. bar
1" x 2"
1" x 2¼"
1" x 1⁹/₁₆"
¾" x 1½"
for ⅝" sq.
for ½" &
for ½" sq.
⅝" sq. bar
* Set screw
included

89/15-16mm 89/16-16mm
89/15-20mm 89/16-20mm EGK82* EGK125* 1-338-1 747/12 747/13 747/14
3⅛" x 1½" 1⁹/₁₆" x 1½" 3⁵/₁₆" x 1 ⅝" 5⅛" x 2⁹/₁₆" 2¹¹/₁₆" x 2⁹/₁₆" 2⁹/₁₆" x 1⁹/₁₆" 2²¹/₃₂" x 1¾" 3¹/₁₆" x 2"
for ⅝" sq. & for ⅝" & for ⁹/₁₆" sq. for 1" sq. for ⅝" sq. for ½" sq. for ⁹/₁₆" sq. for ⅝" sq.
¾" sq. bar ¾" sq. bar
CAST IRON CAST IRON HALF KNUCKLES
CEHK12 - 2" x 1½", fits over ½" sq.
CEHK58 - 1⅞" x 1⅝", its over ⅝" sq.
CEHK34 - 1⅞" x 1⅞", fits over ¾" sq.
CEHK10 - 2½" x 2½", fits over 1" sq.

Note: These half knuckles are meant to cover 3 sides only.
8514 8527 CL8527H CL8527Y
They are not "split" to go around a full spindle.
2" x 2⅛" 1⅞" x 1³/₁₆" 1⅞" x 1¼" 1⅞" x 2" Use for metal work designs that will be applied to screen or
for ½" sq. for ½" sq. for ⅝" sq. for ¾" sq. security doors.
ALUMINUM BRASS CAST IRON / STEEL

* 683S has a set
screw included
CAST IRON
683 fits over ½" sq. 1¾" W x 2" H
683H fits over ⅝" sq. 1⅞" W x 2" H
683Y fits over ¾" sq. 2" W x 2" H
683Z fits over 1" sq. 2½" W x 2½" H
683-AL fits over ½" sq. 1½" W x 1⅞" H 683BR fits over ½" sq. 1¾" W x 2" H 683S* fits over ½" sq. 1½" W x 1⅞" H
683H-AL fits over ⅝" sq. 1¾" W x 1⅞" H 683H-BR fits over ⅝" sq. 1⅞" Wx 2" H STEEL
683Y-AL fits over ¾" sq. 2" W x 1⅞" H 683Y-BR fits over ¾"sq. 2" Wx 2" H 683-ST fits over ½" sq. 1¾" W x 2" H
683H-ST fits over ⅝" sq. 1⅞" W x 2" H
683Z-AL fits over 1" sq. 2½" W x 2" H 683Z-BR fits over 1" sq. 2½" Wx 2½" H 683Y-ST fits over ¾" sq. 2" W x 2" H
683Z-ST fits over 1" sq. 2½" W x 2½" H
683X-ST fits over 1¼" sq. 1½" W x 1⅞" H
A LL DIMENSIONS ARE APPR O XIM ATE .
