Page 239 - Catalog

PANELGRIP 2 GLASS RAILING SYSTEM

Roll Formed Top Rail .059"
18' Lengths.
Type 316.
Mill, Satin or Bright Polished Finish.
These Stainless Steel sections have no visible seam
and are suitable for bending. c
GR3192
b
Type 316 Stainless Steel a
INTERNAL HORIZONTAL
a b c Finish TOP RAIL END CAP SPLICE MITER CORNER

1.50" 3 /4" 1" Satin GR3152.4 GR3152E.4 GR315LS GR3152MK.4

1.50" 3 /4" 1" Polished GR3152.7 GR3152E.7 GR315LS GR3152MK.7
1.66" 3 /4" 1" Satin GR3168.4 GR3169E.4 GR3166S* GR3168MK.4

1.66" 3 /4" 1" Polished GR3168.7 GR3169E.7 GR3166S* GR3168MK.7

1.66" 15 /16" 15 /16" Satin GR3169.4** GR3169E.4 GR3169S* GR3169MK.4
1.90" 3 /4" 1 /4" Satin GR3192.4 GR3193E.4 GR3190S* GR3192MK.4
1
1.90" 3 /4" 1 /4" Polished GR3192.7 GR3193E.7 GR3190S* GR3192MK.7
1
1
1.90" 1 /16" 1 /16" Satin GR3193.4** GR3193E.4 GR3193S* GR3193MK.4
3
* Aluminum for use with Stainless Steel.
** For use with /2" or /4" monolithic or laminated glass. With /4" glass, secure in place with GR95CBC silicone. .109"
3
1
3
GR2190
GR2168 .109"
STAINLESS & CABLE RAILING
Extruded Aluminum Top Rail 1" 1 1 /4"
20' Lengths. Alloy 6063-T52 3 /4" 3 /4"
Suitable for Anodizing. 1.66" 1.90”
For use with glass up to /16" thick.
9
Finish TOP RAIL END CAP INTERNAL SPLICE HORIZONTAL MITER CORNER
Mill GR2168 GR2168EM GR2168S GR2168MK
Satin Anodized GR2168.4AN GR2168EM.AN GR2168S GR2168MK.4AN
Mill GR2190 GR2190EM GR2190S GR2190MK
Satin Anodized GR2190.4AN GR2190EM.AN GR2190S GR2190MK.4AN

Miter Elbows
Top Rail Placing metal Top Rail in
direct contact with a glass
edge is not recommended.
Use Silicone or a Protective
Insert as a buffer between
the Top Rail selected and
Insert Tempered Glass.
End Caps Splices
Protective Insert
This new universal protective insert will work with a
broad range of glass sizes and Top Rail. Attach to top
of glass with adhesive strip provided then expose
top adhesive strip prior to placing Slotted Top Rail
over Insert which will fold sides into place. A silicone
bead may be needed depending on glass/Top Rail
dimensions.
Length PVC Self Adhesive Strips Sold flat in 20, 40, 100 or 250
20' GR9397-20 foot coils. Folds into shape once
40' GR9397-40 1 Slotted Top Rail is put into place.
100' GR9397-100 2 /4" Spray glass cleaner is suggested
250' GR9397 to simplify insertion.
