SHOES AND BASE COLLARS FOR SQUARE BAR

All measurements height x width.All measurements height x width.

CAST IRON
FITS OVER 1/2" SQUARE

9503 8524 8525 EE 9501-CI SS-1/2 8527
ORNAMENTAL METALS 7/8" x 1-1/2" fits over 1/2" fits over 1/2" 7/8" x 2-3/8" 5/8" x 1-11/16" FITS OVER 3/4" SQUARE
2" x 1-1/4"
1" x 1-1/4"
1-7/8" x 1-1/8"
1-1/4" x 2-1/2"
fits over 1/2"
fits over 1/2"
fits over 1/2"
fits over 1/2"
fits over 1/2"
FITS OVER 9/16" SQUARE
FITS OVER 5/8" SQUARE

8524-N 8525-N 8524-H 8525-H EE-5/8 9508 9534 MIS-34
1" x 1-1/4" 2" x 1-1/4" 1" x 1-1/4" 2" x 1-1/4" 1" x 2-1/2" 1-1/4" x 1-5/8" 1" x 3" 1-1/8" x 1-1/4"
fits over 9/16" fits over 9/16" fits over 5/8" fits over 5/8" fits over 5/8" fits over 3/4" fits over 3/4" fits over 3/4"

FITS OVER 1" SQUARE

AA MM SS-1 BB CC 9504 9502-CI

1" x 3" 1-3/8" x 3-3/4" 2-1/8" x 3-3/4" 1-3/8" x 3-3/4" 2" x 3-1/8" 1-1/8" x 2" 1" x 2-1/4"
fits over 1" fits over 1" fits over 1" fits over 1" fits over 1" fits over 1" fits over 1"

FITS OVER 1" SQUARE FITS IN 1" SQUARE FITS OVER 11/4" SQUARE

KK-1 LL MIS-1 FF CL36A

1-1/4" x 3" 1-3/8" x 2-3/4" 1-3/16" x 1-3/4" 1-5/8" x 3" 2-3/8" x 2-3/8"
fits over 1" fits over 1" fits over 1" fits in 1" fits over 1-1/4"

FITS OVER 11/4" SQUARE FITS OVER 11/2" SQUARE

MIS-114 9540 9506 RR 9550 HH MIS-112
1-1/2" x 2-3/4" 1-1/2" x 3-1/4" 1-3/4" x 2-7/8" 1-1/4" x 3-7/8" 2" x 3-3/4" 2" x 3-3/4" 1-3/4" x 3"
fits over 1-1/4" fits over 1-1/4" fits over 1-1/4" fits over 1-1/4" fits over 1-1/2" fits over 1-1/2" fits over 1-1/2"
A LL DIMENSIONS ARE APPR O XIM ATE .
