SIDE MOUNT BRACKETS
To install balusters on the side of the stringer.
Angle Brackets Forged Steel Brackets Steel Bracket with Oval Mounting
Install the baluster in place by Holes and Cast Iron Cap
means of welding or screwing. IRON & STEEL RAILINGS
Supplied with a M10 double NOT SUITABLE FOR HOT DIP GALVANIZING.
thread screw. To fix balusters on the side of the stringer: Steel bracket
with oval holes and cast iron cap.
STEEL
45mm 1 4 /5”
SUP6
94/A/2 1-427
Height: 6-5/16" Height: 10-5/8"
Wall Plate Size: 3-23/32" Wall Plate Size: 4-3/8" 90mm 3 1 /2”
Size of Bar: 1/2" Size of Bar: 1/2"
BRASS SUP9 55 mm
2 3 /16”
Steel Bracket with
Oval Mounting Holes
SPL6
The brass parts are
polished and lacquered.
Bottom rail bracket consists of an 8 mm thick For indoor use only.
steel plate and a support arm formed from
square steel bar. The brass
covering pieces are 120mm 4 3 /4”
polished and
lacquered.
20mm
For indoor 3 /4"
use only. 60mm
2 3 /8”
SPL13
120mm 4 3 /4"
90mm
3 1 /2"
SPL33
A LL DIMENSIONS ARE APPR O XIM ATE .
