Page 304 - CATALOG

1½" & 2" STAINLESS STEEL RAILING SYSTEM

FITTINGS ARE AVAILABLE IN A 304 SS 40-POLISHED • 304 SS 44-SATIN • 316 SS 47-POLISHED • 316 SS 49-SATIN FINISH
1-1/2" AND 2" TUBING

A T A T

Satin Stainless Steel Polished Stainless Steel
Round Tubing Round Tubing

Catalog # A(in.) T(in.) Lb./Ft. Mill Ft. Catalog # A(in.) T(in.) Lb./Ft. Mill Ft.
44-A110 1-1/2 .050 .832 20 40-A110 1-1/2 .050 .832 20
44-A120 2 .050 1.080 20 40-A120 2 .050 1.080 20

POST BRACKETS

CP CP Steel Sleeve for

D 340 Flush End Post Round Tubing, 12FT
D
342 Flush Center Post
Catalog #
Use with Tubing Lb./Ft.
STAINLESS & CABLE RAILING ITEM # TUBING CP D ITEM # TUBING CP D 20-A110SL A110 1.328
A120
1.922
20-A120SL
40-340/1-1/2
40-342/1-1/2
1-1/2" 2-7/16" 2-5/16"
1-1/2" 2-7/16" 2-5/16"
44-342/1-1/2
44-340/1-1/2

348 Low Saddle Post 348L Tall Saddle Post
ITEM # TUBING CP D ITEM # TUBING CP D
49-348/1-1/2 1-1/2" 3-7/8" 3" 49-348L/1-1/2 1-1/2" 6-1/8" 3"
49-348/2 2" 3-7/8" 3" 49-348L/2 2" 6-1/4" 3"
FOOTRAIL BRACKETS

CP CP
CP

H
B B

402 Bar Mount Bracket
400 Combination Bracket 406 Contemporary Bracket ITEM # TUBING CP B
ITEM # TUBING CP H ITEM # TUBING CP B 40-402/1-1/2 1-1/2" 6-1/16" 4"
40-400/1-1/2 1-1/2" 6-7/16" 6-5/8" 40-406/2 2" 6-1/16" 2-7/8" 44-402/1-1/2
44-400/1-1/2 44-406/2 40-402/2 2" 6-7/8" 4-1/4"
40-400/2 2" 6-1/8" 7" 44-402/2
44-400/2 * Bar Mount Bracket may be bolted from back
A LL DIMENSIONS ARE APPR O XIM ATE . side for additional strength.
