REGENCY RAILINGS WINDSOR I PANELS U.S. PATENT #7,594,643 B2
Windsor©

Windsor I hoops are 5/8" square bar and the center bar of piece C & D is 3/8" round.

Windsor I is sold in sets and includes one hoop, two collars, two fleur de lis,
two threaded rods, and one center medallion.
IRON & STEEL RAILINGS Available in steel and aluminum (see page 194).

PIECE A
PIECE D
PIECE B
PIECE C
IS SUPPLIED WITH A USE WITH PIECE A IS SUPPLIED WITH A USE WITH PIECE B
STRAIGHT OR ANGLED STRAIGHT OR ANGLED
COLLAR. PLEASE COLLAR. PLEASE
CHOOSE ITEM FOR YOUR CHOOSE ITEM FOR YOUR
APPLICATION. APPLICATION.

Collar
See page
87 for more
examples.

STEEL PIECE A & C STEEL PIECE B & D ALUMINUM PIECE A & C ALUMINUM PIECE B & D
For straight applications WIN A1C-0 WIN B1D-0 WIN A1AC-0 WIN B1AD-0
Fits angles 21° to 27° WIN A1C-24 WIN B1D-24 WIN A1AC-24 WIN B1AD-24
Fits angles 28° to 34° WIN A1C-31 WIN B1D-31 WIN A1AC-31 WIN B1AD-31
Fits angles 35° to 42° WIN A1C-39 WIN B1D-39 WIN A1AC-39 WIN B1AD-39
Fits angles 43° to 49° WIN A1C-46 WIN B1D-46 WIN A1AC-46 WIN B1AD-46

HOOP ONLY
WIN A1 Piece A in Steel
WIN A1A Piece A in Aluminum

WIN B1 Piece B in Steel
WIN B1A Piece B in Aluminum

A LL DIMENSIONS ARE APPR O XIM ATE .
