GATE OPERATOR ACCESSORIES

TWOBUTTON SWITCH THREEBUTTON SWITCH

2512 2510
• Actuate button is N.O • Open button is N.O
• Stop Button is N.C. • Close button is N.O
• Switch rating 10 A / 250VAC • Stop Button is N.C.
• Dimensions: • Switch rating 10 A / 250VAC
4 in. wide x 2.87 in. high x 2.25 in. deep • Dimensions:
(102 x 73 x 57 mm) 4 in. wide x 2.87 in. high x 2.25 in. deep
(102 x 73 x 57 mm)

EXIT BUTTON
1211080

• Provides a release device for doors secured
with a magnetic lock or electric strike
• Lighted Exit push buttons
• 12-volt DC power (for light)
• 1211-081 designed for mullion mounting
• 4-1/2" H x 2-13/16"W (114.3mm H x 71.4mm W)

ELECTRO MAGNETIC LOCK WITH OR
WITHOUT HANDLE

Magnetic lock with or without handle. Available in 2 versions.
MAGMAG-2500 with 600 lb. and MAGMAG-5000 with 1200 lb. of pulling
force. The aluminum powdercoated housing equipped with
the unique Quick-Fix fixings ensures a fast and nicely finished mounting.
Eliminate time-consuming welding; drilling 5 holes is enough to fix
the lock. A two layer, protective coating guarantees that our electro-
magnetic locks are ready for years of worry free use outside.
• High holding force! Up to 1200 lb/500 kg
• 500h salt spray resistant! MAGMAG2500SL - Silver without Handle
• Special two-layer protective coating developed for outdoor use MAGMAG2500BL - Black without Handle
• SGS Certified For mounting on square posts and gate profiles of
• Powdercoated aluminum casing 1-1/2" to 3-1/8", 600 lbs. pulling force
• Anti-residual magnetism kick-off system
• New anti-pry system: Raised edge on the magnet housing makes it MAGMAG5000SL - Silver without Handle
impossible to put a crowbar between the magnet and the armature MAGMAG5000BL - Black without Handle
plate
• No-handle version For mounting on square posts and gate profiles of
• Fast and easy fixing by means of 5 holes with Quick-Fix 1-1/2" to 3-1/8", 1200 lbs. pulling force
• Same center-distance as the standard Locinox keeps
• Fail open MAG2500SL - Silver with Handle
• MAG2500/MAGMAG2500: Minimal pulling force: 2500N (600 lb) MAG2500BL - Black with Handle
• MAG5000/MAGMAG5000: Minimal pulling force: 5000N (1200 lb) For mounting on square posts and gate profiles of
• Voltage: 12V/24V DC 1-1/2" to 3-1/8", 600 lbs. pulling force
• Current MAG2500/MAGMAG2500: 460 mA / 12 V or 230 mA / 24 V
• Current MAG5000/MAGMAG5000: 460 mA / 12 V or 230 mA / 24 V
MAG5000SL - Silver with Handle
MAG5000BL - Black with Handle
For mounting on square posts and gate profiles of
1-1/2" to 3-1/8", 1200 lbs. pulling force
