DRIVEWAY LOOPS AND VEHICLE DETECTORS

PREFORMED DIRECT
BURIAL LOOPS

BD Loops direct burial loops are
designed for quick and easy installation
and can be installed in concrete or under
asphalt, pavers or gravel roads.
PREFORMED SAWCUT LOOPS
• 16 AWG loop wire designed for superior performance. Used for saw-cut installations where a 3/16" groove is cut into the
• Installation kit includes: cable ties, ground stakes, and loop lead-in concrete or asphalt and the wire is stued and sealed (using loop
labels. sealant) into the groove. Custom polyethylene outer jacket protects a
• Easy to follow installation instructions. micro-dusted nylon coated inner jacketed 16AWG stranded wire. The
• Loop wire is durable and rated for direct burial. saw-cut loop has a built in backer-rod securely tting a 3/16" saw-cut
• Pre-phased (phasing direction marked) at the factory, allowing groove eliminating the need to apply backer-rod to hold the loop
installers to easily take advantage of loop phasing. to the bottom of the saw-cut groove and requires 30-40% less loop
sealant to seal the groove. Both the loop and the lead-in t within a
3/16" saw-cut groove preventing wasted time spent double saw-
Reverse/Shadow Loops Free Exit Loops
cutting or doubling blades to cut the home run lead-in.
EL24-60 – 24 foot Loop EL36-100 – 36 foot Loop
4' x 8' loop, 60ft lead wire 6' x 12' loop, 100ft lead wire Reverse/Shadow Loops Free Exit Loops
RL36-40 – 36 foot Loop EL44-100 – 44 foot Loop SC24-50 – 24 foot Loop SC36-100 – 36 foot Loop
6' x 12' loop, 40ft lead wire 6' x 16' loop, 100ft lead wire 4' x 8' loop, 50ft lead wire 6' x 12' loop, 100ft lead wire
EL44-60 – 44 foot Loop SC36-50 – 36 foot Loop SC44-100 – 44 foot Loop
6' x 16' loop, 60ft lead wire 6' x 12' loop, 50ft lead wire 6' x 16' loop, 100ft lead wire
SC44-50 – 44 foot Loop
6' x 16' loop, 50ft lead wire
LOOP SEALANT
Polyurethane sealant has many advantages when compared to other
commonly used sealants. VEHICLE DETECTOR
• Does not shrink or crack—it does not BDLG-BLACKTUBE DSP7LP
have an evaporation cure like most other BDLG-GRAYTUBE
sealants. Detector operates on any voltage
• Does not conduct electricity—water based 30 fl. oz. tube from 10 to 30 volts AC or DC and
sealants can facilitate shorts to ground. draws about 1 milliamp of current
• Has a low viscosity (ows easily) is easier on BDLG-BLACKCASE with no vehicle on the loop. This
your hand, and is self leveling. BDLG-GRAYCASE micro-sized detector will automatically adjust its sensitivity
• Can be cleaned up with rubbing alcohol. Case of 12 level when used on dierent sized loops. The detector loop
inductance should be between 20 and 2000 microhenries.
CARTELL GATEMATE™ FREE EXIT SYSTEM • Designed for solar powered applications
• Designed to be cross talk free between other loops
CP31005W 100' of wire • Automatically compensates for loop and lead-In sizes
• Switchless, self-adapting to most common installations
CP32005W 200' of wire • Plug and play; Connect it up and watch it work
The Cartell-GateMate™ free exit system is a self- • Small prole, perfect for many installations
contained unit. All the electronics are contained in • Fail safe operation
the sensor probe housing. There is no external output board to install. • Wide low-voltage operation
Bury the Cartell-GateMate™ 6-10 inches underground, 100 feet from
the automatic gate operator (toward the house), beside and parallel
to the driveway. It should be hooked up directly to the free exit
terminals on the gate operator. Universal voltage (AC and DC) makes it VEHICLE DETECTOR KIT
compatible with any gate operator, solar or powered.
KEXITPROBE
FEATURES: • Universal voltage AC and DC
• Based on magnetometer • Electronics full encased in The Diablo “Mini-Loop” is intended
technology polyurethane to be buried beneath the roadway
• Buried beside driveway, hidden • Spliceable cable for easy eld surface and connected, via lead-in
and vandal-proof repairs cable, to the Diablo DML-9LP
• Covers 12 foot wide driveway • Two models: 3 wire and 5 wire Detector. Installation costs may
• Self-contained with no output • Five wire model has N.O., N.C. be signicantly less than those
board to install contacts for conventional loops, because
• Lowest stand-by current on • Works with any and all gate only single, straight 1/4" saw cuts
market (85-90% lower than its closest operators need to be made and a 1" diameter hole drilled about 20" deep. Also
competition) • • RFI/EMF protection resulting is the opportunity for greatly increased service life due to the
reduced exposure to hazards such as road trac, pavement movement,
Made and supported in the U.S.
Low power consumption
•
