ALUMINUM PIPE FITTINGS BY

ELBOWS
*
These elbows are precision mandrel bent parts - without seams - except as noted with an .

90° Elbow 90° Elbow
1-5/8" internal radius 1/8" inside radius 3 /4" Side Outlet Elbow a 3 /4"
PIPE WALL PIPE SIZE TUBE OD ALUMINUM PIPE SIZE TUBE OD A ALUMINUM
SIZE OD THICKNESS ALUMINUM 1-1/4" 1.66" 806* 1-1/4" 1.66" 1-9/16" 842*
1-1/4" 1.66" .140" 4444 1-1/2" 1.90" 824* 1-1/2" 1.90" 1-11/16" 843*
1-1/2" 1.90" .145" 4474 ALLOY: Aluminum: 3003 ALLOY: Aluminum: 3003
ALLOYS: Aluminum: 3003 Seamed Elbows, 6063 Pipe Elbows
PIPE
180° Elbow with t
Two 2" Tangents
2" inside radius, trimmed Aluminum Pipe
PIPE WALL Alloy 6063, 20' Lengths,
SIZE OD THICKNESS ALUMINUM Mill Finish OD
ALUMINUM RAILINGS 1-1/2" 1.90" .145" 365-6 PIPE SIZE SCH. OD ID T LB/FT ALUMINUM
.140"
293-6
1-1/4"
1.66"
1.38" .140"
1.66"
P490
.786
40
1-1/4"
ALLOYS: Aluminum: 3003 Seamed Elbows, 6063 Pipe Elbows
P540
.940
1.90"
40
1-1/2"
1.61" .145"
WEDGELOCK WELDING CONNECTORS INTERNAL SLEEVES
1 /8"
3 /4"
Internal Sleeve
May be used with Aluminum or
Stainless Steel. Ribbed outer surface.
EXTRUDED
Wedge-Lock Welding Connectors for Pipe and PIPE SCH. TUBE OD TUBE ID LENGTH ALUMINUM

SIZE
Round Tubing 1-1/4" 40 1.66" 1.38" 4" IR70E-7
PIPE TUBE 1-1/2" 40 1.90" 1.62" 5" SA517
SIZE SCH. OD WALL ALUMINUM
1-1/4" 40 1.66" .140" 1024
1-1/2" 40 1.90" .145" 1034
FLANGES END CAPS
See page 42 for dimensions.
Flange with Four Heavy Base Plain
Plain Flange Holes Flange with Set Screw* Type A Machined Drive-On End
Cap for Schedule 40 Pipe, Alloy
PIPE PIPE PIPE
SIZE OD ALUMINUM SIZE OD ALUMINUM SIZE OD ALUMINUM 6063 Aluminum
1-1/4" 1.66" 1630 1-1/4" 1.66" 1633 1-1/4" 1.66" 1469 Deburr inside of pipe to give chamfered
1-1/2" 1.90" 1640 1-1/2" 1.90" 1643 1-1/2" 1.90" 1477 caps an easy start.
* 1/4"-20 set screw - not for structural use.
PIPE MILL FINISH
SIZE ALUMINUM
1-1/4" 3231AM
1-1/2" 3232AM
Snap-On Cover Canopy Flange Type E Flat Machined
4-1/2" diameter, 18 gauge. Cover has
Snap-On Cover Flange Base clearance for 3/8" bolt heads. This canopy Drive-On Cap
4-3/8" diameter base has four clear flange drops into place. Use epoxy or For schedule 40 pipe size only.
mounting holes for 3/8" bolts. silicone to affix to heavy duty weld flange. 6063T52 Aluminum
PIPE MILL FINISH
PIPE COVER 3003 PIPE COVER 3003 SIZE ALUMINUM
SIZE OD DIAM. THICK. ALUMINUM SIZE OD DIAM. HT. ALUMINUM
1-1/4" 1.66" 4-3/8" .25" 2066B 1-1/4" 1.66" 4-1/2" 1" 2066 1-1/4" 3291M
1-1/2" 1.90" 4-3/8" .25" 2076B 1-1/2" 1.90" 4-1/2" 1" 2076 1-1/2" 3292M
* Thickness = .188".
A LL DIMENSIONS ARE APPR O XIM ATE .
