ORNAMENTAL CAST IRON BALUSTERS
(SBO)=Side backed out (concave on back) (SF)=Single faced (no design on back)
All castings double faced unless otherwise specied.
IRON & STEEL RAILINGS
1" 1½" ½"
solid ends solid ends solid ends 30° pitch
89-BXL 89-C 89-L 9644 9643 9645 (SF)
2¼" W x 36" H 2" W x 36" H 1¼" W x 35¾" H 3½" W x 29" H 3½" W x 28½" H 19½" W x 28½" H
1"
Grind end solid ends
to bevel
20° pitch
8504 7615 7614 89-B
14" W x 30¾" H 4⅝" W x 27⅝" H 4½" W x 27¾" H 2¼" W x 32¾" H
2 Panel Illustration
A LL DIMENSIONS ARE APPR O XIM ATE .
