ALUMINUM COVER PLATES, FLANGES & SHOES

8050-NH - for 2-1/2"
5" sq. base 1" H 7 Ga.
8098-NH - for 3"
5" sq. base 5/8" H 7 Ga.
A simple, inexpensive nishing touch 8078 - 3/4" Cover Plate,
for anodized or powder coated rails. 2" sq. base 7/16" H 10 Ga. CAST ALUMINUM SPLIT SHOE
Slip on style (non-weldable).
8080 - 1" Cover Plate,
MR-1/2" for 1/2" 2-1/4" sq. base 2" sq. base 3/8" H 10 Ga.
MR-5/8" for 5/8" 2-1/4" sq. base 8082 - 1-1/4" Cover Plate,
MR-3/4" for 3/4" 2-1/4" sq. base 3" sq. base 5/8" H 10 Ga.
MR-1" for 1" 2-5/8" sq. base
MR-1-1/4" for 1-1/4" 3-1/8" sq. base 8084 - 1-1/2" Cover Plate,
MR-1-1/2" for 1-1/2" 3-1/4" sq. base 3" sq. base 5/8" H 10 Ga. ALUMINUM RAILINGS
MR-2" for 2" 4" sq. base 8086 - 2" Cover Plate
MR-2-1/2" for 2-1/2" 5" sq. base 4" sq. base 1/" H 7 Ga. 245A-58 for 5/8” sq. bar
245A-34 for 3/4” sq. bar
245A-1 for 1” sq. bar
AM-1-1/4" for 1-1/4" 3" sq. base 16 Ga. 245A-114 for 1-1/4” sq. bar
245A-112 for 1-1/2” sq. bar
AM-1-1/2" for 1-1/2" 3" sq. base 16 Ga. 245A-158 for 1-5/8” sq. bar
AM-2" for 2" 4" sq. base 16 Ga. 245A-2 for 2” sq. bar
AM-2-1/2" for 2-1/2" 5" sq. base 16 Ga. 245A-212 for 2-1/2” sq. bar
245A-3 for 3” sq. bar
245A-312 for 3-1/2” sq. bar
245A-4 for 4” sq. bar

BASE PLATE

CP-1" for 1" 3-3/4" sq. base 1448/9
CP-1-1/4" for 1-1/4" 3-3/4" sq. base 2156-SHOE 5/16" thick
CP-1-1/2" for 1-1/2" 3-7/8" sq. base 1-1/2" sq. 4" W x 4" H
CP-2" for 2" 3-7/8" sq. base 3-5/8" W x 1-3/4 H

SIMSHOE CAST ALUMINUM SHOES

FINALLY, THE FIRST AND ONLY PLASTIC 9502
SPLIT-COVER STYLE SHOE!
While traditional cover for 1" sq.
shoes must be on the post 2-1/2" W x 1" H
before the baseplate is
welded to it, Simshoe ™
allows you to put your AL12
shoes on last.
for 1-1/2" sq. 3-1/2" W x 2" H

SS1-3 fits over 1" 3" x 3" base
SS114-3 fits over 1-1/4" 3" x 3" base AL22
SS112-3 fits over 1-1/2" 3" x 3" base for 2" sq. 4-1/2" W x 2" H
SS112-4 fits over 1-1/2" 4" x 4" base
SS2-4 fits over 2" 4" x 4" base
