GATE FRAME ENDS AND SHAPED GATE FRAME TOPS

BLOCKS FOR CORNERS OF GATES lock plates

ORNAMENTAL METALS FRAME ENDS IN 7/23A for 1-1/2" x 1-1/2" (40 x 40 12-49/S 12-49/D

mm) frames (illustrated)
PLAIN FLAT BAR
7/23B for 1-1/4" x 1-1/4" (30 x 30 6-19/64" W x 10-5/8" H 6-19/64" W x 10-5/8" H
Approx. 8" long mm) frames 3/16" thick 3/16" thick
available in the 7/23C for 2" x 2" (50 x 50 mm) frames
following sizes.

7/22 1-1/4" x 3/8"
7/21 1-1/2" x 3/8" 7/21 forged scroll Reversible lock plate
1-1/2" x 3/8"
7/62 2" x 3/8" 5-15/16" W x 11-7/16" H
7/23A 3/16" thick
solid or
box frame
1-1/2" x 1-1/2" Sold Individually
(40 x 40 mm)
94/1

long swept arch

8/11B 1-9/16" x 3/8", Plain Flat Bar
17-23/32 Rise
70-7/8" Long

short swept arch

8/13C 1-3/16" x 3/8", Plain Flat Bar
8-7/8" Rise
39-3/8" Long

shadow rail top arch

NOTE: Rolled on the edge. Use 2 arches,
one in the front and one in back with 8/15C 1" x 3/8", Plain Flat Bar
uprights in between. 17-23/32 Rise
70-7/8" Long
