BRASS HANDRAILS FROM
LUXURY RAILINGS

OPTIONAL GOLD NICKEL CHROME SATIN ROSE
FINISHES (G) (NI) BLACK (SA) GOLD (RG)
(CN)

190mm
7 1 /2”

260mm 10 1 /4”
R = 95mm
R = 3 3 /4»

For MCL45 COL45 COL45P For MCL45 CUL45 CUL45P
For MCL50 COL50 COL50P For MCL50 CUL50 CUL50P
For MCL60 - COL60P For MCL60 - CUL60P

“LATERAL“ bottom rail scroll made
“LATERAL“ scrolls for MCL45, MCL50 and MCL60 are supplied in solid polished of a 20 x 12mm (¾" x ½") steel bar.
brass. Use with DL51, steel scroll 20x12mm, ¾" x ½".
Fit for use left or right.
FOR DL 45/50/60 L&R.
150mm 103mm
20 5 7 /8" 4 1 /16"

100mm 3 15 /16"

140mm 5 1 /2”

DL45L For MCL45 DL45R
DL50L For MCL50 DL50R 20 x 12 mm DL51
3/4" x 1/2"
DL60L For MCL60 DL60R

Brass finial bases, polished and lacquered or 24-carat gold Brass volute-end, polished. Polished brass
plated : “G”. Items for indoor use only. Recessed to receive a coverjoint collar.
20 x 12 mm bar (¾" x ½").

60mm
60mm
60mm
2 3 /8”
Passing Base 2 3 /8” 2 3 /8” For MCL45 DRL45 For MCL45 RAL45
Base for Angle
Extremity Base
For MCL50 DRL50 For MCL50 RAL50
TSL1 TSL2 TSL3 For MCL60 DRL60 For MCL60 RAL60
A LL DIMENSIONS ARE APPR O XIM ATE .
