ROSETTES AND QUATREFOILS
CAST IRON
(SBO)=Side backed out (concave on back) (SF)=Single faced (no design on back)
All castings double faced unless otherwise specied.
ORNAMENTAL METALS
681 (SF) 681-DF 9051 (SF) 9051-DF 9052 (SF) 9052-DF
4" 4" 1⅞" 1⅞" 2½" 2½"
9050 (SF) 9050-DF 9053 (SF) 9053-DF 9054 (SF) 9054-DF
3⅛" 3⅛" 3½" 3½" 2" W x 3⅜" H 2" W x 3⅜" H
PAIR ONLY
(2 make full-bodied
rosette, or t 1/4" rod)
9469-R (SBO) 9465 (SF) 9479-R 9555 (SF) 9471-R
2½" W x 6½" H 5¼" W x 8⅞" H 4" W x 4½" H 3" 3⅛" W x 5¼" H
1" thick in center ¾" deep
QUATREFOIL
17/1 1019/2 1010/3 24/2 24/3
9-27/32" , 9-13/32" , 11-7/16" , 15" , 23-5/8" ,
matl. size 5/16" sq. matl. size 1/2" sq. matl. size 1/2" sq. matl. size 3/8" x 3/16" matl. size 1/2" sq.
A LL DIMENSIONS ARE APPR O XIM ATE .
